| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G08_064T01_9000001814_12276cztM0_level2.evt | modeM0/AS1G08_064T01_9000001814_12276cztM0_level2_quad_clean.evt |
| Size (bytes) | 627,022,080 | 77,558,400 |
| Size | 598.0 MB | 74.0 MB |
| Events in quadrant A | 4,119,191 | 470,145 |
| Events in quadrant B | 6,817,584 | 469,599 |
| Events in quadrant C | 3,281,675 | 474,691 |
| Events in quadrant D | 4,304,196 | 453,804 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10 | 0 |
| B | 0 | 10 | 0 |
| C | 0 | 10 | 0 |
| D | 0 | 10 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 140 | 0 |
| B | 0 | 140 | 0 |
| C | 0 | 140 | 0 |
| D | 0 | 140 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16699 | 3 |
| B | 0 | 24726 | 2 |
| C | 0 | 14265 | 2 |
| D | 0 | 17337 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6887 | 157 | 2.279657% |
| B | 6887 | 1445 | 20.981559% |
| C | 6887 | 89 | 1.292290% |
| D | 6887 | 238 | 3.455786% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7904 | 6890 | 10 | 10 | 0.13% | 0.15% |  |
| B | 7904 | 6890 | 967 | 967 | 12.23% | 14.03% |  |
| C | 7904 | 6890 | 7 | 7 | 0.09% | 0.10% |  |
| D | 7904 | 6890 | 120 | 120 | 1.52% | 1.74% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 5 | 16 | 160611 | 927.92 | 850 | 834 | 172.2 |
| A | 1 | 162 | 132364 | 763.87 | 850 | 834 | 172.2 |
| A | 13 | 251 | 123847 | 714.41 | 850 | 834 | 172.2 |
| B | 4 | 239 | 1833088 | 12787.95 | 755 | 737 | 143.3 |
| B | 0 | 85 | 1452004 | 10128.37 | 755 | 737 | 143.3 |
| B | 3 | 64 | 310430 | 2161.34 | 755 | 737 | 143.3 |
| C | 14 | 234 | 39479 | 204.44 | 824 | 826 | 189.1 |
| C | 3 | 233 | 20564 | 104.4 | 824 | 826 | 189.1 |
| C | 13 | 61 | 6107 | 27.93 | 824 | 826 | 189.1 |
| D | 1 | 52 | 409571 | 2051.76 | 824 | 801 | 199.2 |
| D | 13 | 104 | 212988 | 1065.04 | 824 | 801 | 199.2 |
| D | 10 | 157 | 202062 | 1010.2 | 824 | 801 | 199.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
