| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G08_064T01_9000001814_12287cztM0_level2.evt | modeM0/AS1G08_064T01_9000001814_12287cztM0_level2_quad_clean.evt |
| Size (bytes) | 414,175,680 | 80,464,320 |
| Size | 395.0 MB | 76.7 MB |
| Events in quadrant A | 3,038,153 | 514,772 |
| Events in quadrant B | 3,558,382 | 516,990 |
| Events in quadrant C | 2,640,066 | 514,479 |
| Events in quadrant D | 2,916,500 | 489,208 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 116 | 0 |
| B | 0 | 116 | 0 |
| C | 0 | 116 | 0 |
| D | 0 | 116 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12538 | 2 |
| B | 0 | 14209 | 1 |
| C | 0 | 11676 | 1 |
| D | 0 | 12448 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5740 | 58 | 1.010453% |
| B | 5740 | 196 | 3.414634% |
| C | 5740 | 19 | 0.331010% |
| D | 5740 | 43 | 0.749129% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 6990 | 5741 | 0 | 0 | 0.00% | 0.00% |  |
| B | 6991 | 5742 | 100 | 100 | 1.43% | 1.74% |  |
| C | 6990 | 5741 | 0 | 0 | 0.00% | 0.00% |  |
| D | 6990 | 5741 | 18 | 18 | 0.26% | 0.31% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 1 | 162 | 105569 | 733.89 | 704 | 691 | 142.9 |
| A | 1 | 178 | 61147 | 423.05 | 704 | 691 | 142.9 |
| A | 1 | 161 | 52048 | 359.37 | 704 | 691 | 142.9 |
| B | 3 | 64 | 328493 | 2524.67 | 689 | 672 | 129.8 |
| B | 4 | 239 | 307187 | 2360.59 | 689 | 672 | 129.8 |
| B | 0 | 85 | 61145 | 465.72 | 689 | 672 | 129.8 |
| C | 13 | 61 | 4787 | 26.53 | 675 | 677 | 154.9 |
| C | 4 | 254 | 4579 | 25.19 | 675 | 677 | 154.9 |
| C | 14 | 234 | 3466 | 18.0 | 675 | 677 | 154.9 |
| D | 1 | 52 | 141512 | 868.57 | 677 | 659 | 162.2 |
| D | 10 | 199 | 54754 | 333.58 | 677 | 659 | 162.2 |
| D | 2 | 234 | 27980 | 168.48 | 677 | 659 | 162.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
