| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G08_064T01_9000001814_12288cztM0_level2.evt | modeM0/AS1G08_064T01_9000001814_12288cztM0_level2_quad_clean.evt |
| Size (bytes) | 502,295,040 | 94,317,120 |
| Size | 479.0 MB | 89.9 MB |
| Events in quadrant A | 3,493,187 | 613,358 |
| Events in quadrant B | 4,240,156 | 617,726 |
| Events in quadrant C | 3,190,291 | 612,224 |
| Events in quadrant D | 3,865,971 | 578,433 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14 | 0 |
| B | 0 | 14 | 0 |
| C | 0 | 14 | 0 |
| D | 0 | 15 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 126 | 0 |
| B | 0 | 126 | 0 |
| C | 0 | 126 | 0 |
| D | 0 | 126 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14308 | 3 |
| B | 0 | 16441 | 2 |
| C | 0 | 13348 | 2 |
| D | 0 | 15425 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6228 | 88 | 1.412974% |
| B | 6228 | 478 | 7.675016% |
| C | 6228 | 75 | 1.204239% |
| D | 6228 | 185 | 2.970456% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7509 | 6230 | 3 | 3 | 0.04% | 0.05% |  |
| B | 7509 | 6230 | 279 | 279 | 3.72% | 4.48% |  |
| C | 7509 | 6230 | 41 | 41 | 0.55% | 0.66% |  |
| D | 7509 | 6230 | 121 | 121 | 1.61% | 1.94% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 1 | 162 | 108758 | 671.36 | 794 | 778 | 160.8 |
| A | 15 | 174 | 91210 | 562.26 | 794 | 778 | 160.8 |
| A | 1 | 178 | 60810 | 373.25 | 794 | 778 | 160.8 |
| B | 4 | 239 | 899606 | 6448.33 | 746 | 729 | 139.4 |
| B | 3 | 64 | 168890 | 1206.35 | 746 | 729 | 139.4 |
| B | 0 | 85 | 94465 | 672.44 | 746 | 729 | 139.4 |
| C | 1 | 16 | 179343 | 1029.81 | 757 | 762 | 173.4 |
| C | 4 | 254 | 56176 | 319.55 | 757 | 762 | 173.4 |
| C | 13 | 61 | 5536 | 27.53 | 757 | 762 | 173.4 |
| D | 1 | 52 | 614319 | 3435.02 | 756 | 736 | 178.6 |
| D | 9 | 85 | 105571 | 586.9 | 756 | 736 | 178.6 |
| D | 13 | 104 | 71619 | 396.82 | 756 | 736 | 178.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
