| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A04_130T01_9000001822_12340cztM0_level2.evt | modeM0/AS1A04_130T01_9000001822_12340cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,376,176,320 | 223,672,320 |
| Size | 1.3 GB | 213.3 MB |
| Events in quadrant A | 10,106,872 | 1,404,829 |
| Events in quadrant B | 11,453,550 | 1,357,591 |
| Events in quadrant C | 8,939,986 | 1,398,449 |
| Events in quadrant D | 9,946,065 | 1,357,013 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 20 | 0 |
| B | 0 | 20 | 0 |
| C | 0 | 20 | 0 |
| D | 0 | 20 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 42232 | 4 |
| B | 0 | 45943 | 3 |
| C | 0 | 39238 | 3 |
| D | 0 | 42250 | 3 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 370 | 0 |
| B | 0 | 370 | 0 |
| C | 0 | 370 | 0 |
| D | 0 | 370 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 18230 | 161 | 0.883160% |
| B | 18230 | 922 | 5.057597% |
| C | 18230 | 226 | 1.239715% |
| D | 18230 | 393 | 2.155787% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 20146 | 18234 | 3 | 3 | 0.01% | 0.02% |  |
| B | 20146 | 18234 | 577 | 577 | 2.86% | 3.16% |  |
| C | 20146 | 18234 | 128 | 128 | 0.64% | 0.70% |  |
| D | 20146 | 18234 | 318 | 318 | 1.58% | 1.74% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 15 | 472739 | 1098.47 | 2122 | 2079 | 428.5 |
| A | 1 | 162 | 456143 | 1059.74 | 2122 | 2079 | 428.5 |
| A | 13 | 251 | 328347 | 761.47 | 2122 | 2079 | 428.5 |
| B | 0 | 85 | 2064661 | 5218.58 | 2085 | 2032 | 395.2 |
| B | 4 | 239 | 674294 | 1700.87 | 2085 | 2032 | 395.2 |
| B | 3 | 64 | 134854 | 336.05 | 2085 | 2032 | 395.2 |
| C | 4 | 254 | 797286 | 1663.33 | 2060 | 2072 | 478.1 |
| C | 15 | 208 | 102664 | 210.4 | 2060 | 2072 | 478.1 |
| C | 13 | 61 | 15007 | 27.05 | 2060 | 2072 | 478.1 |
| D | 1 | 52 | 1264554 | 2551.91 | 2057 | 2000 | 494.7 |
| D | 13 | 122 | 207556 | 415.47 | 2057 | 2000 | 494.7 |
| D | 13 | 104 | 150191 | 299.53 | 2057 | 2000 | 494.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
