| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G08_072T03_9000001836_12374cztM0_level2.evt | modeM0/AS1G08_072T03_9000001836_12374cztM0_level2_quad_clean.evt |
| Size (bytes) | 654,088,320 | 81,305,280 |
| Size | 623.8 MB | 77.5 MB |
| Events in quadrant A | 3,956,241 | 517,351 |
| Events in quadrant B | 8,876,236 | 471,801 |
| Events in quadrant C | 3,174,987 | 532,688 |
| Events in quadrant D | 3,375,589 | 500,634 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | 130 | 0 |
| D | 0 | 130 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16030 | 3 |
| B | 0 | 30581 | 2 |
| C | 0 | 13230 | 2 |
| D | 0 | 14083 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 25 | 0 |
| B | 0 | 25 | 0 |
| C | 0 | 25 | 0 |
| D | 0 | 25 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6292 | 70 | 1.112524% |
| B | 6292 | 2424 | 38.525111% |
| C | 6292 | 33 | 0.524476% |
| D | 6292 | 88 | 1.398601% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8793 | 6293 | 2 | 2 | 0.02% | 0.03% |  |
| B | 8792 | 6293 | 2215 | 2215 | 25.19% | 35.20% |  |
| C | 8792 | 6293 | 3 | 3 | 0.03% | 0.05% |  |
| D | 8792 | 6293 | 45 | 45 | 0.51% | 0.72% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 1 | 162 | 222015 | 1382.82 | 802 | 786 | 160.0 |
| A | 13 | 251 | 213893 | 1332.06 | 802 | 786 | 160.0 |
| A | 1 | 178 | 120562 | 748.68 | 802 | 786 | 160.0 |
| B | 2 | 32 | 3682477 | 28576.0 | 693 | 677 | 128.8 |
| B | 2 | 48 | 1982337 | 15380.5 | 693 | 677 | 128.8 |
| B | 4 | 239 | 422548 | 3274.32 | 693 | 677 | 128.8 |
| C | 15 | 208 | 35040 | 185.53 | 803 | 810 | 184.5 |
| C | 14 | 234 | 10969 | 55.06 | 803 | 810 | 184.5 |
| C | 13 | 61 | 5791 | 27.0 | 803 | 810 | 184.5 |
| D | 1 | 52 | 183707 | 973.67 | 784 | 764 | 187.9 |
| D | 2 | 14 | 98859 | 522.09 | 784 | 764 | 187.9 |
| D | 10 | 199 | 70589 | 371.63 | 784 | 764 | 187.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
