| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G08_072T03_9000001836_12377cztM0_level2.evt | modeM0/AS1G08_072T03_9000001836_12377cztM0_level2_quad_clean.evt |
| Size (bytes) | 849,375,360 | 61,945,920 |
| Size | 810.0 MB | 59.1 MB |
| Events in quadrant A | 3,868,729 | 389,204 |
| Events in quadrant B | 12,789,573 | 278,996 |
| Events in quadrant C | 3,902,246 | 396,223 |
| Events in quadrant D | 4,724,962 | 358,645 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | 130 | 0 |
| D | 0 | 130 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15609 | 3 |
| B | 0 | 42334 | 2 |
| C | 0 | 15795 | 2 |
| D | 0 | 18301 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 20 | 0 |
| B | 0 | 20 | 0 |
| C | 0 | 20 | 0 |
| D | 0 | 21 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6478 | 180 | 2.778635% |
| B | 6478 | 4773 | 73.680148% |
| C | 6478 | 159 | 2.454461% |
| D | 6478 | 614 | 9.478234% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7534 | 6479 | 2 | 2 | 0.03% | 0.03% |  |
| B | 7533 | 6478 | 4589 | 4589 | 60.92% | 70.84% |  |
| C | 7534 | 6479 | 59 | 59 | 0.78% | 0.91% |  |
| D | 7534 | 6479 | 547 | 547 | 7.26% | 8.44% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 1 | 162 | 157107 | 952.89 | 814 | 799 | 164.0 |
| A | 13 | 251 | 144037 | 873.21 | 814 | 799 | 164.0 |
| A | 8 | 15 | 129716 | 785.91 | 814 | 799 | 164.0 |
| B | 2 | 48 | 5474975 | 57794.75 | 505 | 493 | 94.7 |
| B | 2 | 32 | 4762279 | 50270.74 | 505 | 493 | 94.7 |
| B | 4 | 239 | 335078 | 3532.25 | 505 | 493 | 94.7 |
| C | 15 | 208 | 728003 | 3917.66 | 804 | 808 | 185.6 |
| C | 14 | 234 | 23505 | 122.28 | 804 | 808 | 185.6 |
| C | 6 | 96 | 19075 | 98.41 | 804 | 808 | 185.6 |
| D | 1 | 52 | 1705536 | 9097.78 | 779 | 757 | 187.4 |
| D | 8 | 195 | 28842 | 149.88 | 779 | 757 | 187.4 |
| D | 13 | 104 | 24822 | 128.43 | 779 | 757 | 187.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
