| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G08_083T02_9000001840_12408cztM0_level2.evt | modeM0/AS1G08_083T02_9000001840_12408cztM0_level2_quad_clean.evt |
| Size (bytes) | 343,992,960 | 35,890,560 |
| Size | 328.1 MB | 34.2 MB |
| Events in quadrant A | 3,027,023 | 202,814 |
| Events in quadrant B | 2,840,318 | 205,298 |
| Events in quadrant C | 1,806,064 | 207,355 |
| Events in quadrant D | 2,481,412 | 198,297 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 2 | 0 |
| B | 0 | 2 | 0 |
| C | 0 | 2 | 0 |
| D | 0 | 3 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 76 | 0 |
| B | 0 | 76 | 0 |
| C | 0 | 76 | 0 |
| D | 0 | 76 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11617 | 1 |
| B | 0 | 10898 | 1 |
| C | 0 | 8065 | 1 |
| D | 0 | 9899 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 3861 | 364 | 9.427609% |
| B | 3861 | 448 | 11.603212% |
| C | 3861 | 63 | 1.631702% |
| D | 3861 | 181 | 4.687905% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 3862 | 3862 | 234 | 234 | 6.06% | 6.06% |  |
| B | 3862 | 3862 | 254 | 254 | 6.58% | 6.58% |  |
| C | 3862 | 3862 | 8 | 8 | 0.21% | 0.21% |  |
| D | 3862 | 3862 | 113 | 113 | 2.93% | 2.93% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 14 | 237 | 830453 | 8971.46 | 446 | 435 | 92.5 |
| A | 13 | 251 | 152928 | 1648.26 | 446 | 435 | 92.5 |
| A | 12 | 189 | 100934 | 1086.27 | 446 | 435 | 92.5 |
| B | 4 | 239 | 1016233 | 11782.02 | 440 | 430 | 86.2 |
| B | 0 | 219 | 23409 | 266.53 | 440 | 430 | 86.2 |
| B | 3 | 209 | 20583 | 233.75 | 440 | 430 | 86.2 |
| C | 15 | 208 | 58614 | 552.48 | 447 | 448 | 105.3 |
| C | 14 | 234 | 3352 | 27.58 | 447 | 448 | 105.3 |
| C | 13 | 61 | 3326 | 27.34 | 447 | 448 | 105.3 |
| D | 1 | 52 | 529483 | 4903.05 | 443 | 429 | 107.9 |
| D | 10 | 199 | 122915 | 1135.15 | 443 | 429 | 107.9 |
| D | 7 | 71 | 29200 | 266.63 | 443 | 429 | 107.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
