| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A04_201T01_9000001844_12419cztM0_level2.evt | modeM0/AS1A04_201T01_9000001844_12419cztM0_level2_quad_clean.evt |
| Size (bytes) | 521,280,000 | 94,610,880 |
| Size | 497.1 MB | 90.2 MB |
| Events in quadrant A | 4,301,125 | 600,947 |
| Events in quadrant B | 4,230,084 | 621,535 |
| Events in quadrant C | 3,128,467 | 611,262 |
| Events in quadrant D | 3,681,958 | 573,615 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14 | 0 |
| B | 0 | 14 | 0 |
| C | 0 | 14 | 0 |
| D | 0 | 15 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 134 | 0 |
| B | 0 | 134 | 0 |
| C | 0 | 134 | 0 |
| D | 0 | 134 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 17070 | 3 |
| B | 0 | 16679 | 2 |
| C | 0 | 13617 | 2 |
| D | 0 | 15324 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6561 | 165 | 2.514861% |
| B | 6561 | 394 | 6.005182% |
| C | 6561 | 53 | 0.807804% |
| D | 6561 | 152 | 2.316720% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7812 | 6562 | 78 | 78 | 1.00% | 1.19% |  |
| B | 7812 | 6562 | 253 | 253 | 3.24% | 3.86% |  |
| C | 7812 | 6562 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7812 | 6563 | 100 | 100 | 1.28% | 1.52% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 251 | 847375 | 5044.9 | 822 | 805 | 167.8 |
| A | 1 | 162 | 91576 | 540.93 | 822 | 805 | 167.8 |
| A | 12 | 189 | 48019 | 281.36 | 822 | 805 | 167.8 |
| B | 4 | 239 | 791592 | 5234.31 | 806 | 788 | 151.1 |
| B | 3 | 64 | 183924 | 1212.17 | 806 | 788 | 151.1 |
| B | 0 | 187 | 35569 | 230.21 | 806 | 788 | 151.1 |
| C | 15 | 208 | 18990 | 99.38 | 797 | 800 | 183.0 |
| C | 13 | 61 | 6004 | 28.43 | 797 | 800 | 183.0 |
| C | 14 | 234 | 2325 | 8.33 | 797 | 800 | 183.0 |
| D | 1 | 52 | 340294 | 1808.92 | 786 | 765 | 187.7 |
| D | 8 | 195 | 138230 | 732.38 | 786 | 765 | 187.7 |
| D | 2 | 14 | 81408 | 429.64 | 786 | 765 | 187.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
