| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A04_174T01_9000001850_12460cztM0_level2.evt | modeM0/AS1A04_174T01_9000001850_12460cztM0_level2_quad_clean.evt |
| Size (bytes) | 692,706,240 | 93,620,160 |
| Size | 660.6 MB | 89.3 MB |
| Events in quadrant A | 9,095,610 | 523,929 |
| Events in quadrant B | 3,770,644 | 654,399 |
| Events in quadrant C | 3,038,360 | 643,341 |
| Events in quadrant D | 4,650,436 | 575,221 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 31500 | 3 |
| B | 0 | 15250 | 2 |
| C | 0 | 13050 | 2 |
| D | 0 | 18082 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16 | 0 |
| B | 0 | 16 | 0 |
| C | 0 | 16 | 0 |
| D | 0 | 17 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 126 | 0 |
| B | 0 | 126 | 0 |
| C | 0 | 126 | 0 |
| D | 0 | 126 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6270 | 2124 | 33.875598% |
| B | 6270 | 132 | 2.105263% |
| C | 6270 | 24 | 0.382775% |
| D | 6270 | 362 | 5.773525% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7515 | 6270 | 1867 | 1867 | 24.84% | 29.78% |  |
| B | 7516 | 6271 | 61 | 61 | 0.81% | 0.97% |  |
| C | 7516 | 6272 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7516 | 6271 | 289 | 289 | 3.85% | 4.61% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 23 | 3329424 | 22810.0 | 715 | 702 | 145.9 |
| A | 13 | 251 | 2477096 | 16969.44 | 715 | 702 | 145.9 |
| A | 0 | 226 | 259870 | 1775.94 | 715 | 702 | 145.9 |
| B | 4 | 239 | 488010 | 3259.84 | 798 | 782 | 149.5 |
| B | 0 | 85 | 48743 | 320.89 | 798 | 782 | 149.5 |
| B | 0 | 187 | 30697 | 200.15 | 798 | 782 | 149.5 |
| C | 13 | 61 | 5832 | 28.15 | 778 | 786 | 179.3 |
| C | 14 | 234 | 3000 | 12.35 | 778 | 786 | 179.3 |
| C | 12 | 4 | 2788 | 11.17 | 778 | 786 | 179.3 |
| D | 1 | 52 | 1598901 | 8864.06 | 749 | 730 | 180.3 |
| D | 13 | 104 | 99414 | 547.34 | 749 | 730 | 180.3 |
| D | 8 | 195 | 61897 | 339.26 | 749 | 730 | 180.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
