| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A04_230T01_9000001854_12534cztM0_level2.evt | modeM0/AS1A04_230T01_9000001854_12534cztM0_level2_quad_clean.evt |
| Size (bytes) | 467,202,240 | 91,964,160 |
| Size | 445.6 MB | 87.7 MB |
| Events in quadrant A | 3,526,635 | 590,632 |
| Events in quadrant B | 3,497,486 | 604,563 |
| Events in quadrant C | 3,121,443 | 600,106 |
| Events in quadrant D | 3,585,622 | 559,875 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 20 | 0 |
| B | 0 | 20 | 0 |
| C | 0 | 20 | 0 |
| D | 0 | 21 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 124 | 0 |
| B | 0 | 124 | 0 |
| C | 0 | 124 | 0 |
| D | 0 | 124 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14566 | 3 |
| B | 0 | 14283 | 2 |
| C | 0 | 13275 | 2 |
| D | 0 | 14809 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6161 | 79 | 1.282259% |
| B | 6161 | 132 | 2.142509% |
| C | 6161 | 56 | 0.908943% |
| D | 6161 | 132 | 2.142509% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7522 | 6163 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7522 | 6163 | 24 | 24 | 0.32% | 0.39% |  |
| C | 7522 | 6163 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7522 | 6163 | 46 | 46 | 0.61% | 0.75% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 1 | 162 | 150325 | 909.77 | 811 | 796 | 164.4 |
| A | 1 | 178 | 89854 | 541.85 | 811 | 796 | 164.4 |
| A | 1 | 161 | 75527 | 454.68 | 811 | 796 | 164.4 |
| B | 4 | 239 | 144799 | 932.09 | 817 | 799 | 154.5 |
| B | 0 | 230 | 95043 | 610.03 | 817 | 799 | 154.5 |
| B | 0 | 190 | 25890 | 162.41 | 817 | 799 | 154.5 |
| C | 13 | 61 | 5916 | 27.69 | 800 | 806 | 184.5 |
| C | 9 | 221 | 3176 | 12.84 | 800 | 806 | 184.5 |
| C | 3 | 202 | 1979 | 6.36 | 800 | 806 | 184.5 |
| D | 1 | 52 | 239825 | 1279.62 | 783 | 763 | 186.8 |
| D | 13 | 249 | 183119 | 976.09 | 783 | 763 | 186.8 |
| D | 8 | 195 | 112547 | 598.34 | 783 | 763 | 186.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
