| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A04_085T01_9000001868_12573cztM0_level2.evt | modeM0/AS1A04_085T01_9000001868_12573cztM0_level2_quad_clean.evt |
| Size (bytes) | 440,614,080 | 84,061,440 |
| Size | 420.2 MB | 80.2 MB |
| Events in quadrant A | 3,153,973 | 521,621 |
| Events in quadrant B | 3,218,526 | 537,361 |
| Events in quadrant C | 3,178,044 | 519,849 |
| Events in quadrant D | 3,341,014 | 502,876 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 136 | 0 |
| B | 0 | 136 | 0 |
| C | 0 | 136 | 0 |
| D | 0 | 136 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13801 | 3 |
| B | 0 | 13949 | 2 |
| C | 0 | 13912 | 2 |
| D | 0 | 14557 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 9 | 0 |
| B | 0 | 9 | 0 |
| C | 0 | 9 | 0 |
| D | 0 | 9 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6649 | 71 | 1.067830% |
| B | 6649 | 76 | 1.143029% |
| C | 6649 | 62 | 0.932471% |
| D | 6649 | 125 | 1.879982% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7645 | 6650 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7645 | 6650 | 0 | 0 | 0.00% | 0.00% |  |
| C | 7645 | 6650 | 8 | 8 | 0.10% | 0.12% |  |
| D | 7645 | 6650 | 68 | 68 | 0.89% | 1.02% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 96 | 11880 | 67.72 | 809 | 793 | 163.7 |
| A | 12 | 189 | 10136 | 57.06 | 809 | 793 | 163.7 |
| A | 1 | 162 | 8259 | 45.6 | 809 | 793 | 163.7 |
| B | 3 | 209 | 24405 | 152.09 | 813 | 795 | 155.2 |
| B | 12 | 111 | 17722 | 109.04 | 813 | 795 | 155.2 |
| B | 11 | 111 | 14945 | 91.15 | 813 | 795 | 155.2 |
| C | 15 | 208 | 89649 | 486.97 | 786 | 789 | 182.5 |
| C | 14 | 234 | 11381 | 58.05 | 786 | 789 | 182.5 |
| C | 14 | 67 | 10033 | 50.66 | 786 | 789 | 182.5 |
| D | 1 | 52 | 141772 | 746.82 | 784 | 760 | 188.8 |
| D | 13 | 249 | 132750 | 699.04 | 784 | 760 | 188.8 |
| D | 11 | 18 | 30244 | 156.15 | 784 | 760 | 188.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
