| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G08_071T01_9000001874_12589cztM0_level2.evt | modeM0/AS1G08_071T01_9000001874_12589cztM0_level2_quad_clean.evt |
| Size (bytes) | 509,160,960 | 74,082,240 |
| Size | 485.6 MB | 70.7 MB |
| Events in quadrant A | 3,343,418 | 451,152 |
| Events in quadrant B | 3,821,237 | 454,699 |
| Events in quadrant C | 3,131,266 | 453,259 |
| Events in quadrant D | 4,684,293 | 432,061 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | 130 | 0 |
| D | 0 | 130 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14359 | 3 |
| B | 0 | 15784 | 2 |
| C | 0 | 13653 | 2 |
| D | 0 | 18401 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18 | 0 |
| B | 0 | 18 | 0 |
| C | 0 | 18 | 0 |
| D | 0 | 19 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6485 | 70 | 1.079414% |
| B | 6485 | 167 | 2.575173% |
| C | 6485 | 45 | 0.693909% |
| D | 6485 | 426 | 6.569005% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7571 | 6486 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7571 | 6486 | 60 | 60 | 0.79% | 0.93% |  |
| C | 7571 | 6486 | 4 | 4 | 0.05% | 0.06% |  |
| D | 7571 | 6486 | 331 | 331 | 4.37% | 5.10% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 5 | 112 | 220373 | 1342.74 | 802 | 786 | 163.5 |
| A | 12 | 189 | 33891 | 202.43 | 802 | 786 | 163.5 |
| A | 0 | 226 | 7169 | 39.03 | 802 | 786 | 163.5 |
| B | 4 | 239 | 433384 | 2834.17 | 798 | 780 | 152.6 |
| B | 3 | 64 | 105753 | 687.72 | 798 | 780 | 152.6 |
| B | 11 | 51 | 60172 | 389.1 | 798 | 780 | 152.6 |
| C | 15 | 208 | 58530 | 318.3 | 787 | 791 | 181.4 |
| C | 13 | 61 | 5623 | 26.64 | 787 | 791 | 181.4 |
| C | 3 | 233 | 3137 | 12.93 | 787 | 791 | 181.4 |
| D | 1 | 52 | 1658971 | 9063.54 | 765 | 745 | 183.0 |
| D | 13 | 249 | 52443 | 282.57 | 765 | 745 | 183.0 |
| D | 13 | 104 | 26589 | 141.26 | 765 | 745 | 183.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
