| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G08_071T01_9000001874_12594cztM0_level2.evt | modeM0/AS1G08_071T01_9000001874_12594cztM0_level2_quad_clean.evt |
| Size (bytes) | 421,519,680 | 90,158,400 |
| Size | 402.0 MB | 86.0 MB |
| Events in quadrant A | 2,867,632 | 577,109 |
| Events in quadrant B | 3,145,830 | 598,053 |
| Events in quadrant C | 2,984,176 | 587,974 |
| Events in quadrant D | 3,348,132 | 536,107 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 126 | 0 |
| B | 0 | 126 | 0 |
| C | 0 | 126 | 0 |
| D | 0 | 126 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12750 | 3 |
| B | 0 | 13443 | 2 |
| C | 0 | 13126 | 2 |
| D | 0 | 14386 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 20 | 0 |
| B | 0 | 20 | 0 |
| C | 0 | 20 | 0 |
| D | 0 | 21 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6173 | 14 | 0.226794% |
| B | 6173 | 55 | 0.890977% |
| C | 6173 | 33 | 0.534586% |
| D | 6173 | 206 | 3.337113% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7409 | 6175 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7409 | 6175 | 17 | 17 | 0.23% | 0.28% |  |
| C | 7409 | 6175 | 26 | 26 | 0.35% | 0.42% |  |
| D | 7409 | 6175 | 200 | 200 | 2.70% | 3.24% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 189 | 14870 | 94.67 | 737 | 721 | 149.5 |
| A | 15 | 239 | 9270 | 57.2 | 737 | 721 | 149.5 |
| A | 3 | 1 | 8169 | 49.83 | 737 | 721 | 149.5 |
| B | 4 | 239 | 145525 | 1037.26 | 744 | 725 | 139.6 |
| B | 3 | 64 | 78010 | 553.62 | 744 | 725 | 139.6 |
| B | 0 | 214 | 17669 | 121.38 | 744 | 725 | 139.6 |
| C | 15 | 208 | 104812 | 622.12 | 726 | 729 | 167.3 |
| C | 14 | 234 | 48942 | 288.18 | 726 | 729 | 167.3 |
| C | 13 | 61 | 5341 | 27.57 | 726 | 729 | 167.3 |
| D | 1 | 52 | 526903 | 3160.87 | 695 | 676 | 166.5 |
| D | 13 | 104 | 80434 | 479.08 | 695 | 676 | 166.5 |
| D | 10 | 199 | 59554 | 353.66 | 695 | 676 | 166.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
