| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G08_071T01_9000001874_12605cztM0_level2.evt | modeM0/AS1G08_071T01_9000001874_12605cztM0_level2_quad_clean.evt |
| Size (bytes) | 516,559,680 | 88,136,640 |
| Size | 492.6 MB | 84.1 MB |
| Events in quadrant A | 3,125,432 | 571,495 |
| Events in quadrant B | 4,960,256 | 535,801 |
| Events in quadrant C | 3,182,773 | 579,518 |
| Events in quadrant D | 3,954,563 | 549,020 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 124 | 0 |
| B | 0 | 124 | 0 |
| C | 0 | 124 | 0 |
| D | 0 | 124 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13504 | 3 |
| B | 0 | 19032 | 2 |
| C | 0 | 13672 | 2 |
| D | 0 | 16070 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6211 | 30 | 0.483014% |
| B | 6211 | 767 | 12.349058% |
| C | 6211 | 50 | 0.805023% |
| D | 6212 | 193 | 3.106890% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7467 | 6212 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7467 | 6212 | 576 | 576 | 7.71% | 9.27% |  |
| C | 7467 | 6213 | 21 | 21 | 0.28% | 0.34% |  |
| D | 7468 | 6213 | 118 | 118 | 1.58% | 1.90% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 3 | 1 | 45745 | 281.81 | 794 | 779 | 159.6 |
| A | 12 | 189 | 17824 | 106.82 | 794 | 779 | 159.6 |
| A | 0 | 226 | 7125 | 39.77 | 794 | 779 | 159.6 |
| B | 4 | 239 | 1962340 | 14129.91 | 743 | 727 | 138.8 |
| B | 3 | 209 | 28985 | 203.55 | 743 | 727 | 138.8 |
| B | 0 | 197 | 28407 | 199.38 | 743 | 727 | 138.8 |
| C | 15 | 208 | 107540 | 596.0 | 786 | 791 | 179.1 |
| C | 14 | 234 | 10901 | 56.45 | 786 | 791 | 179.1 |
| C | 13 | 61 | 5765 | 27.77 | 786 | 791 | 179.1 |
| D | 1 | 52 | 853776 | 4631.59 | 769 | 749 | 184.2 |
| D | 1 | 255 | 69550 | 373.56 | 769 | 749 | 184.2 |
| D | 13 | 249 | 37271 | 198.3 | 769 | 749 | 184.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
