| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G08_071T01_9000001874_12616cztM0_level2.evt | modeM0/AS1G08_071T01_9000001874_12616cztM0_level2_quad_clean.evt |
| Size (bytes) | 523,805,760 | 67,386,240 |
| Size | 499.5 MB | 64.3 MB |
| Events in quadrant A | 3,330,410 | 397,958 |
| Events in quadrant B | 3,832,048 | 403,469 |
| Events in quadrant C | 3,222,034 | 399,059 |
| Events in quadrant D | 5,018,999 | 367,073 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 138 | 0 |
| B | 0 | 138 | 0 |
| C | 0 | 138 | 0 |
| D | 0 | 138 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14237 | 3 |
| B | 0 | 15764 | 2 |
| C | 0 | 14078 | 2 |
| D | 0 | 19559 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 11 | 0 |
| D | 0 | 12 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6779 | 72 | 1.062104% |
| B | 6779 | 192 | 2.832276% |
| C | 6779 | 55 | 0.811329% |
| D | 6779 | 454 | 6.697153% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7695 | 6780 | 2 | 2 | 0.03% | 0.03% |  |
| B | 7695 | 6780 | 95 | 95 | 1.23% | 1.40% |  |
| C | 7695 | 6780 | 4 | 4 | 0.05% | 0.06% |  |
| D | 7695 | 6780 | 325 | 325 | 4.22% | 4.79% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 3 | 1 | 148755 | 875.24 | 822 | 804 | 169.0 |
| A | 12 | 189 | 19386 | 109.93 | 822 | 804 | 169.0 |
| A | 0 | 226 | 7294 | 38.39 | 822 | 804 | 169.0 |
| B | 4 | 239 | 497343 | 3160.75 | 815 | 794 | 157.1 |
| B | 3 | 209 | 35294 | 219.61 | 815 | 794 | 157.1 |
| B | 0 | 214 | 27914 | 172.63 | 815 | 794 | 157.1 |
| C | 15 | 208 | 80523 | 433.22 | 798 | 802 | 184.0 |
| C | 14 | 234 | 30042 | 158.9 | 798 | 802 | 184.0 |
| C | 13 | 61 | 5780 | 27.05 | 798 | 802 | 184.0 |
| D | 1 | 52 | 1311211 | 7063.69 | 770 | 748 | 185.5 |
| D | 10 | 157 | 614753 | 3309.62 | 770 | 748 | 185.5 |
| D | 13 | 249 | 77386 | 413.1 | 770 | 748 | 185.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
