| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A04_130T04_9000001878_12724cztM0_level2.evt | modeM0/AS1A04_130T04_9000001878_12724cztM0_level2_quad_clean.evt |
| Size (bytes) | 457,706,880 | 98,994,240 |
| Size | 436.5 MB | 94.4 MB |
| Events in quadrant A | 3,577,050 | 647,102 |
| Events in quadrant B | 3,941,554 | 639,071 |
| Events in quadrant C | 2,906,556 | 655,493 |
| Events in quadrant D | 3,022,727 | 631,252 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14674 | 2 |
| B | 0 | 15716 | 1 |
| C | 0 | 12635 | 1 |
| D | 0 | 13198 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 124 | 0 |
| B | 0 | 124 | 0 |
| C | 0 | 124 | 0 |
| D | 0 | 124 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6087 | 142 | 2.332840% |
| B | 6087 | 401 | 6.587810% |
| C | 6087 | 15 | 0.246427% |
| D | 6087 | 77 | 1.264991% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7343 | 6089 | 89 | 89 | 1.21% | 1.46% |  |
| B | 7343 | 6089 | 246 | 246 | 3.35% | 4.04% |  |
| C | 7343 | 6089 | 6 | 6 | 0.08% | 0.10% |  |
| D | 7343 | 6089 | 34 | 34 | 0.46% | 0.56% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 239 | 637441 | 4279.24 | 738 | 724 | 148.8 |
| A | 11 | 29 | 41394 | 273.33 | 738 | 724 | 148.8 |
| A | 12 | 189 | 40181 | 265.18 | 738 | 724 | 148.8 |
| B | 4 | 239 | 1027584 | 7506.62 | 723 | 705 | 136.8 |
| B | 0 | 214 | 36664 | 262.87 | 723 | 705 | 136.8 |
| B | 12 | 111 | 15326 | 106.88 | 723 | 705 | 136.8 |
| C | 9 | 221 | 51559 | 301.2 | 731 | 734 | 168.7 |
| C | 13 | 61 | 5320 | 27.18 | 731 | 734 | 168.7 |
| C | 14 | 234 | 4979 | 25.15 | 731 | 734 | 168.7 |
| D | 10 | 199 | 136898 | 795.56 | 721 | 705 | 171.2 |
| D | 1 | 52 | 103059 | 597.89 | 721 | 705 | 171.2 |
| D | 2 | 234 | 20249 | 114.16 | 721 | 705 | 171.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
