| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A04_130T04_9000001878_12726cztM0_level2.evt | modeM0/AS1A04_130T04_9000001878_12726cztM0_level2_quad_clean.evt |
| Size (bytes) | 533,545,920 | 78,586,560 |
| Size | 508.8 MB | 74.9 MB |
| Events in quadrant A | 4,699,175 | 484,044 |
| Events in quadrant B | 3,762,447 | 485,212 |
| Events in quadrant C | 3,002,973 | 491,253 |
| Events in quadrant D | 4,250,842 | 463,616 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18532 | 2 |
| B | 0 | 15540 | 2 |
| C | 0 | 13523 | 2 |
| D | 0 | 17431 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16 | 0 |
| B | 0 | 16 | 0 |
| C | 0 | 16 | 0 |
| D | 0 | 16 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 134 | 0 |
| B | 0 | 134 | 0 |
| C | 0 | 134 | 0 |
| D | 0 | 134 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6531 | 409 | 6.262441% |
| B | 6531 | 259 | 3.965702% |
| C | 6531 | 25 | 0.382790% |
| D | 6531 | 348 | 5.328434% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8048 | 6535 | 155 | 155 | 1.93% | 2.37% |  |
| B | 8048 | 6535 | 117 | 117 | 1.45% | 1.79% |  |
| C | 8048 | 6535 | 0 | 0 | 0.00% | 0.00% |  |
| D | 8048 | 6535 | 266 | 266 | 3.31% | 4.07% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 239 | 1658961 | 10451.4 | 775 | 756 | 158.7 |
| A | 11 | 29 | 29340 | 180.16 | 775 | 756 | 158.7 |
| A | 12 | 189 | 25771 | 157.67 | 775 | 756 | 158.7 |
| B | 4 | 239 | 583764 | 3917.15 | 779 | 759 | 148.8 |
| B | 0 | 214 | 58740 | 389.57 | 779 | 759 | 148.8 |
| B | 0 | 205 | 41698 | 275.07 | 779 | 759 | 148.8 |
| C | 13 | 61 | 5577 | 26.66 | 769 | 773 | 180.2 |
| C | 8 | 222 | 2642 | 10.37 | 769 | 773 | 180.2 |
| C | 3 | 202 | 1862 | 6.04 | 769 | 773 | 180.2 |
| D | 1 | 52 | 1150087 | 6465.53 | 747 | 729 | 177.8 |
| D | 2 | 136 | 77004 | 429.07 | 747 | 729 | 177.8 |
| D | 10 | 199 | 68645 | 382.05 | 747 | 729 | 177.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
