| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A04_044T01_9000001882_12753cztM0_level2.evt | modeM0/AS1A04_044T01_9000001882_12753cztM0_level2_quad_clean.evt |
| Size (bytes) | 634,610,880 | 93,769,920 |
| Size | 605.2 MB | 89.4 MB |
| Events in quadrant A | 6,145,910 | 594,731 |
| Events in quadrant B | 4,752,044 | 573,719 |
| Events in quadrant C | 3,633,215 | 615,353 |
| Events in quadrant D | 4,237,271 | 591,126 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 22933 | 3 |
| B | 0 | 18510 | 2 |
| C | 0 | 15310 | 2 |
| D | 0 | 16990 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16 | 0 |
| B | 0 | 16 | 0 |
| C | 0 | 16 | 0 |
| D | 0 | 17 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 136 | 0 |
| B | 0 | 136 | 0 |
| C | 0 | 136 | 0 |
| D | 0 | 136 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6660 | 440 | 6.606607% |
| B | 6660 | 676 | 10.150150% |
| C | 6660 | 134 | 2.012012% |
| D | 6660 | 258 | 3.873874% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7786 | 6662 | 292 | 292 | 3.75% | 4.38% |  |
| B | 7786 | 6662 | 430 | 430 | 5.52% | 6.45% |  |
| C | 7786 | 6662 | 72 | 72 | 0.92% | 1.08% |  |
| D | 7786 | 6662 | 169 | 169 | 2.17% | 2.54% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 222 | 2364841 | 14102.34 | 824 | 807 | 167.6 |
| A | 0 | 23 | 535720 | 3190.95 | 824 | 807 | 167.6 |
| A | 0 | 226 | 41875 | 244.99 | 824 | 807 | 167.6 |
| B | 4 | 239 | 1256798 | 8347.18 | 794 | 776 | 150.5 |
| B | 0 | 85 | 252908 | 1675.6 | 794 | 776 | 150.5 |
| B | 3 | 64 | 45820 | 299.35 | 794 | 776 | 150.5 |
| C | 15 | 208 | 502924 | 2690.86 | 802 | 807 | 186.6 |
| C | 13 | 61 | 5902 | 27.3 | 802 | 807 | 186.6 |
| C | 14 | 234 | 3948 | 16.83 | 802 | 807 | 186.6 |
| D | 1 | 52 | 970571 | 4958.95 | 800 | 776 | 195.6 |
| D | 2 | 136 | 80723 | 408.8 | 800 | 776 | 195.6 |
| D | 13 | 172 | 57812 | 291.65 | 800 | 776 | 195.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
