| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G08_071T01_9000001888_12825cztM0_level2.evt | modeM0/AS1G08_071T01_9000001888_12825cztM0_level2_quad_clean.evt |
| Size (bytes) | 501,802,560 | 82,768,320 |
| Size | 478.6 MB | 78.9 MB |
| Events in quadrant A | 3,355,576 | 524,708 |
| Events in quadrant B | 4,817,829 | 502,228 |
| Events in quadrant C | 3,192,951 | 526,230 |
| Events in quadrant D | 3,397,083 | 507,422 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | 130 | 0 |
| D | 0 | 130 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18 | 0 |
| B | 0 | 18 | 0 |
| C | 0 | 18 | 0 |
| D | 0 | 19 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13965 | 3 |
| B | 0 | 18607 | 2 |
| C | 0 | 13441 | 2 |
| D | 0 | 14255 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6386 | 108 | 1.691199% |
| B | 6386 | 681 | 10.663952% |
| C | 6386 | 95 | 1.487629% |
| D | 6386 | 118 | 1.847792% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7612 | 6388 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7612 | 6388 | 382 | 382 | 5.02% | 5.98% |  |
| C | 7612 | 6388 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7612 | 6388 | 18 | 18 | 0.24% | 0.28% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 189 | 74870 | 439.65 | 837 | 821 | 168.4 |
| A | 15 | 222 | 57694 | 337.67 | 837 | 821 | 168.4 |
| A | 0 | 226 | 7511 | 39.72 | 837 | 821 | 168.4 |
| B | 4 | 239 | 1446081 | 9775.24 | 788 | 770 | 147.9 |
| B | 0 | 219 | 158306 | 1065.48 | 788 | 770 | 147.9 |
| B | 0 | 197 | 50659 | 337.42 | 788 | 770 | 147.9 |
| C | 13 | 61 | 6093 | 28.11 | 818 | 823 | 187.5 |
| C | 14 | 234 | 4699 | 20.67 | 818 | 823 | 187.5 |
| C | 3 | 233 | 1889 | 5.69 | 818 | 823 | 187.5 |
| D | 1 | 52 | 131501 | 661.35 | 815 | 793 | 197.6 |
| D | 13 | 172 | 64417 | 321.92 | 815 | 793 | 197.6 |
| D | 13 | 104 | 58154 | 290.23 | 815 | 793 | 197.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
