| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G08_071T01_9000001888_12830cztM0_level2.evt | modeM0/AS1G08_071T01_9000001888_12830cztM0_level2_quad_clean.evt |
| Size (bytes) | 614,805,120 | 106,064,640 |
| Size | 586.3 MB | 101.2 MB |
| Events in quadrant A | 3,821,814 | 677,958 |
| Events in quadrant B | 5,722,719 | 632,656 |
| Events in quadrant C | 3,708,737 | 685,836 |
| Events in quadrant D | 4,813,213 | 648,627 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 168 | 0 |
| B | 0 | 168 | 0 |
| C | 0 | 168 | 0 |
| D | 0 | 168 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 7 | 0 |
| B | 0 | 7 | 0 |
| C | 0 | 7 | 0 |
| D | 0 | 7 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 17018 | 3 |
| B | 0 | 22696 | 2 |
| C | 0 | 16812 | 2 |
| D | 0 | 20125 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 8150 | 39 | 0.478528% |
| B | 8150 | 836 | 10.257669% |
| C | 8150 | 24 | 0.294479% |
| D | 8150 | 172 | 2.110429% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8896 | 8153 | 0 | 0 | 0.00% | 0.00% |  |
| B | 8896 | 8153 | 491 | 491 | 5.52% | 6.02% |  |
| C | 8896 | 8153 | 0 | 0 | 0.00% | 0.00% |  |
| D | 8896 | 8153 | 110 | 110 | 1.24% | 1.35% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 189 | 88698 | 448.47 | 967 | 947 | 195.7 |
| A | 15 | 222 | 16969 | 81.88 | 967 | 947 | 195.7 |
| A | 0 | 226 | 8306 | 37.61 | 967 | 947 | 195.7 |
| B | 4 | 239 | 1674924 | 9631.57 | 909 | 886 | 173.8 |
| B | 0 | 219 | 137860 | 788.08 | 909 | 886 | 173.8 |
| B | 10 | 245 | 116891 | 667.43 | 909 | 886 | 173.8 |
| C | 8 | 222 | 8260 | 33.02 | 949 | 952 | 221.3 |
| C | 13 | 61 | 7014 | 27.39 | 949 | 952 | 221.3 |
| C | 3 | 202 | 2396 | 6.53 | 949 | 952 | 221.3 |
| D | 1 | 52 | 836230 | 3399.91 | 921 | 904 | 245.7 |
| D | 13 | 104 | 290854 | 1180.14 | 921 | 904 | 245.7 |
| D | 8 | 195 | 66200 | 265.76 | 921 | 904 | 245.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
