| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G08_071T01_9000001888_12839cztM0_level2.evt | modeM0/AS1G08_071T01_9000001888_12839cztM0_level2_quad_clean.evt |
| Size (bytes) | 495,250,560 | 73,005,120 |
| Size | 472.3 MB | 69.6 MB |
| Events in quadrant A | 3,508,909 | 445,161 |
| Events in quadrant B | 4,233,493 | 443,281 |
| Events in quadrant C | 3,358,082 | 446,576 |
| Events in quadrant D | 3,465,932 | 431,150 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 128 | 0 |
| B | 0 | 128 | 0 |
| C | 0 | 128 | 0 |
| D | 0 | 128 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18 | 0 |
| B | 0 | 18 | 0 |
| C | 0 | 18 | 0 |
| D | 0 | 19 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14462 | 2 |
| B | 0 | 16769 | 1 |
| C | 0 | 13856 | 1 |
| D | 0 | 14360 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6370 | 151 | 2.370487% |
| B | 6370 | 364 | 5.714286% |
| C | 6370 | 123 | 1.930926% |
| D | 6370 | 131 | 2.056515% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7646 | 6372 | 10 | 10 | 0.13% | 0.16% |  |
| B | 7646 | 6372 | 131 | 131 | 1.71% | 2.06% |  |
| C | 7646 | 6372 | 7 | 7 | 0.09% | 0.11% |  |
| D | 7646 | 6372 | 15 | 15 | 0.20% | 0.24% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 189 | 151448 | 880.13 | 861 | 844 | 171.1 |
| A | 15 | 222 | 38826 | 221.97 | 861 | 844 | 171.1 |
| A | 9 | 143 | 8572 | 45.16 | 861 | 844 | 171.1 |
| B | 4 | 239 | 633842 | 4077.51 | 837 | 819 | 155.2 |
| B | 0 | 219 | 123290 | 788.88 | 837 | 819 | 155.2 |
| B | 3 | 209 | 78471 | 500.18 | 837 | 819 | 155.2 |
| C | 7 | 238 | 77539 | 401.35 | 835 | 842 | 191.1 |
| C | 7 | 239 | 17003 | 84.57 | 835 | 842 | 191.1 |
| C | 13 | 61 | 6207 | 28.07 | 835 | 842 | 191.1 |
| D | 13 | 172 | 97258 | 486.27 | 835 | 811 | 198.3 |
| D | 4 | 95 | 88923 | 444.25 | 835 | 811 | 198.3 |
| D | 1 | 52 | 48374 | 239.81 | 835 | 811 | 198.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
