| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G08_071T01_9000001888_12842cztM0_level2.evt | modeM0/AS1G08_071T01_9000001888_12842cztM0_level2_quad_clean.evt |
| Size (bytes) | 603,218,880 | 97,208,640 |
| Size | 575.3 MB | 92.7 MB |
| Events in quadrant A | 3,497,961 | 627,068 |
| Events in quadrant B | 6,698,684 | 571,505 |
| Events in quadrant C | 3,442,787 | 627,048 |
| Events in quadrant D | 4,126,424 | 602,246 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 150 | 0 |
| B | 0 | 150 | 0 |
| C | 0 | 150 | 0 |
| D | 0 | 150 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15450 | 3 |
| B | 0 | 24935 | 2 |
| C | 0 | 15315 | 2 |
| D | 0 | 17319 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7417 | 103 | 1.388702% |
| B | 7417 | 1394 | 18.794661% |
| C | 7417 | 93 | 1.253876% |
| D | 7417 | 191 | 2.575165% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8653 | 7420 | 0 | 0 | 0.00% | 0.00% |  |
| B | 8653 | 7420 | 974 | 974 | 11.26% | 13.13% |  |
| C | 8653 | 7420 | 0 | 0 | 0.00% | 0.00% |  |
| D | 8653 | 7420 | 66 | 66 | 0.76% | 0.89% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 189 | 43143 | 232.0 | 897 | 878 | 182.2 |
| A | 0 | 226 | 7961 | 38.88 | 897 | 878 | 182.2 |
| A | 12 | 194 | 7013 | 33.67 | 897 | 878 | 182.2 |
| B | 10 | 245 | 2715425 | 17153.85 | 829 | 809 | 158.3 |
| B | 4 | 239 | 322539 | 2033.03 | 829 | 809 | 158.3 |
| B | 0 | 219 | 108734 | 681.99 | 829 | 809 | 158.3 |
| C | 3 | 233 | 12674 | 57.75 | 879 | 884 | 204.2 |
| C | 13 | 61 | 6418 | 27.11 | 879 | 884 | 204.2 |
| C | 14 | 234 | 2836 | 9.56 | 879 | 884 | 204.2 |
| D | 1 | 52 | 370984 | 1762.1 | 871 | 844 | 210.1 |
| D | 13 | 104 | 192200 | 910.98 | 871 | 844 | 210.1 |
| D | 8 | 195 | 91967 | 433.8 | 871 | 844 | 210.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
