| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A04_048T01_9000001890_12866cztM0_level2.evt | modeM0/AS1A04_048T01_9000001890_12866cztM0_level2_quad_clean.evt |
| Size (bytes) | 495,725,760 | 87,197,760 |
| Size | 472.8 MB | 83.2 MB |
| Events in quadrant A | 3,273,162 | 568,496 |
| Events in quadrant B | 4,916,247 | 538,699 |
| Events in quadrant C | 3,101,593 | 568,403 |
| Events in quadrant D | 3,309,989 | 540,769 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 124 | 0 |
| B | 0 | 124 | 0 |
| C | 0 | 124 | 0 |
| D | 0 | 124 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13452 | 3 |
| B | 0 | 18535 | 2 |
| C | 0 | 13032 | 2 |
| D | 0 | 13746 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6071 | 61 | 1.004777% |
| B | 6071 | 692 | 11.398452% |
| C | 6071 | 46 | 0.757701% |
| D | 6071 | 47 | 0.774172% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7352 | 6073 | 1 | 1 | 0.01% | 0.02% |  |
| B | 7352 | 6073 | 467 | 467 | 6.35% | 7.69% |  |
| C | 7352 | 6073 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7352 | 6073 | 7 | 7 | 0.10% | 0.12% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 189 | 64098 | 389.4 | 815 | 800 | 162.6 |
| A | 8 | 15 | 22034 | 130.63 | 815 | 800 | 162.6 |
| A | 9 | 143 | 19477 | 114.9 | 815 | 800 | 162.6 |
| B | 4 | 239 | 1341459 | 9508.67 | 758 | 742 | 141.0 |
| B | 0 | 85 | 365683 | 2588.24 | 758 | 742 | 141.0 |
| B | 3 | 64 | 133362 | 940.57 | 758 | 742 | 141.0 |
| C | 13 | 61 | 5616 | 26.59 | 795 | 804 | 181.0 |
| C | 3 | 202 | 2005 | 6.64 | 795 | 804 | 181.0 |
| C | 3 | 203 | 1788 | 5.44 | 795 | 804 | 181.0 |
| D | 1 | 52 | 252597 | 1368.08 | 791 | 774 | 184.1 |
| D | 2 | 234 | 26838 | 141.6 | 791 | 774 | 184.1 |
| D | 13 | 172 | 16164 | 83.61 | 791 | 774 | 184.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
