| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G08_041T01_9000001892_12875cztM0_level2.evt | modeM0/AS1G08_041T01_9000001892_12875cztM0_level2_quad_clean.evt |
| Size (bytes) | 987,462,720 | 136,056,960 |
| Size | 941.7 MB | 129.8 MB |
| Events in quadrant A | 5,138,737 | 882,115 |
| Events in quadrant B | 12,353,782 | 768,330 |
| Events in quadrant C | 4,880,659 | 883,214 |
| Events in quadrant D | 6,795,096 | 831,434 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 9 | 0 |
| B | 0 | 9 | 0 |
| C | 0 | 9 | 0 |
| D | 0 | 9 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 222 | 0 |
| B | 0 | 222 | 0 |
| C | 0 | 222 | 0 |
| D | 0 | 222 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 22672 | 3 |
| B | 0 | 44104 | 2 |
| C | 0 | 22099 | 2 |
| D | 0 | 27639 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 10901 | 80 | 0.733878% |
| B | 10901 | 2805 | 25.731584% |
| C | 10901 | 32 | 0.293551% |
| D | 10901 | 470 | 4.311531% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 11787 | 10904 | 14 | 14 | 0.12% | 0.13% |  |
| B | 11787 | 10904 | 2007 | 2007 | 17.03% | 18.41% |  |
| C | 11787 | 10904 | 0 | 0 | 0.00% | 0.00% |  |
| D | 11787 | 10904 | 415 | 415 | 3.52% | 3.81% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 15 | 62335 | 232.56 | 1280 | 1250 | 262.7 |
| A | 13 | 248 | 46367 | 171.77 | 1280 | 1250 | 262.7 |
| A | 1 | 162 | 24899 | 90.04 | 1280 | 1250 | 262.7 |
| B | 0 | 85 | 5236075 | 24423.02 | 1125 | 1097 | 214.3 |
| B | 4 | 239 | 2336015 | 10893.21 | 1125 | 1097 | 214.3 |
| B | 0 | 219 | 160511 | 743.72 | 1125 | 1097 | 214.3 |
| C | 13 | 61 | 8909 | 26.06 | 1251 | 1255 | 293.7 |
| C | 3 | 202 | 3143 | 6.43 | 1251 | 1255 | 293.7 |
| C | 8 | 128 | 2931 | 5.71 | 1251 | 1255 | 293.7 |
| D | 1 | 52 | 1140616 | 3830.85 | 1226 | 1190 | 297.4 |
| D | 4 | 95 | 474929 | 1592.75 | 1226 | 1190 | 297.4 |
| D | 8 | 195 | 207036 | 692.07 | 1226 | 1190 | 297.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
