| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C03_001T01_9000001894_12880cztM0_level2.evt | modeM0/AS1C03_001T01_9000001894_12880cztM0_level2_quad_clean.evt |
| Size (bytes) | 594,751,680 | 114,099,840 |
| Size | 567.2 MB | 108.8 MB |
| Events in quadrant A | 3,125,778 | 821,761 |
| Events in quadrant B | 6,689,838 | 687,681 |
| Events in quadrant C | 2,707,595 | 802,610 |
| Events in quadrant D | 5,085,734 | 727,464 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12805 | 2 |
| B | 0 | 23819 | 1 |
| C | 0 | 12067 | 1 |
| D | 0 | 18998 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 122 | 0 |
| B | 0 | 122 | 0 |
| C | 0 | 122 | 0 |
| D | 0 | 122 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5940 | 43 | 0.723906% |
| B | 5940 | 1723 | 29.006734% |
| C | 5940 | 16 | 0.269360% |
| D | 5940 | 628 | 10.572391% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7176 | 5942 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7176 | 5942 | 1204 | 1204 | 16.78% | 20.26% |  |
| C | 7176 | 5942 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7176 | 5942 | 557 | 557 | 7.76% | 9.37% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 189 | 94894 | 636.71 | 731 | 717 | 147.9 |
| A | 1 | 162 | 78323 | 524.68 | 731 | 717 | 147.9 |
| A | 1 | 178 | 45630 | 303.65 | 731 | 717 | 147.9 |
| B | 0 | 85 | 2539669 | 22028.82 | 612 | 597 | 115.3 |
| B | 4 | 239 | 1423114 | 12341.66 | 612 | 597 | 115.3 |
| B | 0 | 219 | 200697 | 1736.05 | 612 | 597 | 115.3 |
| C | 13 | 61 | 5136 | 28.08 | 694 | 696 | 158.1 |
| C | 9 | 15 | 1939 | 7.86 | 694 | 696 | 158.1 |
| C | 3 | 202 | 1750 | 6.67 | 694 | 696 | 158.1 |
| D | 1 | 52 | 2348979 | 14936.06 | 668 | 649 | 157.2 |
| D | 4 | 95 | 126502 | 800.46 | 668 | 649 | 157.2 |
| D | 2 | 14 | 28163 | 175.0 | 668 | 649 | 157.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
