| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C03_001T01_9000001894_12884cztM0_level2.evt | modeM0/AS1C03_001T01_9000001894_12884cztM0_level2_quad_clean.evt |
| Size (bytes) | 478,681,920 | 113,941,440 |
| Size | 456.5 MB | 108.7 MB |
| Events in quadrant A | 3,069,003 | 786,704 |
| Events in quadrant B | 4,592,072 | 737,940 |
| Events in quadrant C | 2,752,807 | 775,239 |
| Events in quadrant D | 3,667,207 | 723,524 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12992 | 2 |
| B | 0 | 17691 | 1 |
| C | 0 | 12418 | 1 |
| D | 0 | 14890 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 124 | 0 |
| B | 0 | 124 | 0 |
| C | 0 | 124 | 0 |
| D | 0 | 124 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10 | 0 |
| B | 0 | 10 | 0 |
| C | 0 | 10 | 0 |
| D | 0 | 10 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6118 | 87 | 1.422033% |
| B | 6118 | 741 | 12.111801% |
| C | 6118 | 63 | 1.029748% |
| D | 6118 | 345 | 5.639098% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7099 | 6120 | 3 | 3 | 0.04% | 0.05% |  |
| B | 7099 | 6120 | 353 | 353 | 4.97% | 5.77% |  |
| C | 7099 | 6120 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7099 | 6119 | 205 | 205 | 2.89% | 3.35% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 1 | 162 | 79188 | 536.82 | 722 | 707 | 146.2 |
| A | 9 | 143 | 55353 | 373.78 | 722 | 707 | 146.2 |
| A | 1 | 178 | 46983 | 316.53 | 722 | 707 | 146.2 |
| B | 4 | 239 | 1149799 | 9018.73 | 676 | 658 | 127.4 |
| B | 0 | 85 | 525376 | 4118.11 | 676 | 658 | 127.4 |
| B | 3 | 209 | 83991 | 654.02 | 676 | 658 | 127.4 |
| C | 3 | 233 | 13536 | 80.32 | 701 | 703 | 159.8 |
| C | 13 | 61 | 5274 | 28.61 | 701 | 703 | 159.8 |
| C | 4 | 112 | 3072 | 14.83 | 701 | 703 | 159.8 |
| D | 1 | 52 | 889188 | 5471.45 | 680 | 658 | 162.4 |
| D | 8 | 195 | 102417 | 626.62 | 680 | 658 | 162.4 |
| D | 4 | 95 | 32220 | 194.35 | 680 | 658 | 162.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
