| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A04_116T01_9000001896_12926cztM0_level2.evt | modeM0/AS1A04_116T01_9000001896_12926cztM0_level2_quad_clean.evt |
| Size (bytes) | 472,452,480 | 116,075,520 |
| Size | 450.6 MB | 110.7 MB |
| Events in quadrant A | 3,503,766 | 795,784 |
| Events in quadrant B | 4,123,194 | 752,711 |
| Events in quadrant C | 2,892,774 | 805,896 |
| Events in quadrant D | 3,393,475 | 754,553 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 120 | 0 |
| B | 0 | 120 | 0 |
| C | 0 | 120 | 0 |
| D | 0 | 120 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14288 | 2 |
| B | 0 | 15878 | 1 |
| C | 0 | 12248 | 1 |
| D | 0 | 13769 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5805 | 194 | 3.341947% |
| B | 5805 | 741 | 12.764858% |
| C | 5805 | 118 | 2.032730% |
| D | 5805 | 326 | 5.615848% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7077 | 5808 | 48 | 48 | 0.68% | 0.83% |  |
| B | 7077 | 5808 | 297 | 297 | 4.20% | 5.11% |  |
| C | 7077 | 5808 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7077 | 5808 | 186 | 186 | 2.63% | 3.20% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 1 | 162 | 146719 | 995.87 | 740 | 727 | 146.6 |
| A | 15 | 223 | 123212 | 835.52 | 740 | 727 | 146.6 |
| A | 15 | 239 | 110554 | 749.18 | 740 | 727 | 146.6 |
| B | 4 | 239 | 1139565 | 8919.6 | 693 | 677 | 127.7 |
| B | 3 | 64 | 197387 | 1540.6 | 693 | 677 | 127.7 |
| B | 0 | 190 | 33407 | 256.34 | 693 | 677 | 127.7 |
| C | 7 | 238 | 68238 | 411.94 | 721 | 725 | 163.9 |
| C | 4 | 112 | 6602 | 35.86 | 721 | 725 | 163.9 |
| C | 13 | 61 | 5413 | 28.6 | 721 | 725 | 163.9 |
| D | 13 | 122 | 471733 | 2791.73 | 711 | 693 | 168.7 |
| D | 8 | 195 | 112473 | 662.49 | 711 | 693 | 168.7 |
| D | 10 | 157 | 38348 | 223.17 | 711 | 693 | 168.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
