| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A04_115T02_9000001900_12931cztM0_level2.evt | modeM0/AS1A04_115T02_9000001900_12931cztM0_level2_quad_clean.evt |
| Size (bytes) | 553,184,640 | 90,406,080 |
| Size | 527.6 MB | 86.2 MB |
| Events in quadrant A | 4,133,773 | 562,919 |
| Events in quadrant B | 4,165,789 | 560,223 |
| Events in quadrant C | 3,307,362 | 569,834 |
| Events in quadrant D | 4,655,730 | 541,136 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 146 | 0 |
| B | 0 | 146 | 0 |
| C | 0 | 146 | 0 |
| D | 0 | 146 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 3 | 0 |
| B | 0 | 3 | 0 |
| C | 0 | 3 | 0 |
| D | 0 | 3 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 17107 | 2 |
| B | 0 | 17254 | 1 |
| C | 0 | 14719 | 1 |
| D | 0 | 18829 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7234 | 85 | 1.175007% |
| B | 7234 | 344 | 4.755322% |
| C | 7234 | 16 | 0.221178% |
| D | 7234 | 376 | 5.197678% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7585 | 7236 | 13 | 13 | 0.17% | 0.18% |  |
| B | 7585 | 7236 | 128 | 128 | 1.69% | 1.77% |  |
| C | 7585 | 7236 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7585 | 7236 | 294 | 294 | 3.88% | 4.06% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 1 | 162 | 225489 | 1275.33 | 861 | 843 | 176.1 |
| A | 12 | 189 | 126917 | 715.73 | 861 | 843 | 176.1 |
| A | 1 | 178 | 119754 | 675.07 | 861 | 843 | 176.1 |
| B | 4 | 239 | 634319 | 3901.34 | 847 | 826 | 162.4 |
| B | 3 | 64 | 148217 | 907.7 | 847 | 826 | 162.4 |
| B | 0 | 214 | 27119 | 161.92 | 847 | 826 | 162.4 |
| C | 8 | 128 | 9506 | 44.08 | 843 | 848 | 196.4 |
| C | 13 | 61 | 6103 | 26.75 | 843 | 848 | 196.4 |
| C | 8 | 112 | 5733 | 24.87 | 843 | 848 | 196.4 |
| D | 1 | 52 | 1472466 | 7405.84 | 818 | 795 | 198.7 |
| D | 8 | 195 | 31084 | 152.42 | 818 | 795 | 198.7 |
| D | 2 | 234 | 27239 | 133.07 | 818 | 795 | 198.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
