| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A04_115T02_9000001900_12942cztM0_level2.evt | modeM0/AS1A04_115T02_9000001900_12942cztM0_level2_quad_clean.evt |
| Size (bytes) | 777,821,760 | 60,851,520 |
| Size | 741.8 MB | 58.0 MB |
| Events in quadrant A | 3,752,278 | 398,334 |
| Events in quadrant B | 4,782,323 | 375,482 |
| Events in quadrant C | 3,307,563 | 401,969 |
| Events in quadrant D | 11,256,691 | 193,623 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 136 | 0 |
| B | 0 | 136 | 0 |
| C | 0 | 136 | 0 |
| D | 0 | 136 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10 | 0 |
| B | 0 | 10 | 0 |
| C | 0 | 10 | 0 |
| D | 0 | 11 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15355 | 3 |
| B | 0 | 18429 | 2 |
| C | 0 | 14069 | 2 |
| D | 0 | 37799 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6769 | 109 | 1.610282% |
| B | 6769 | 678 | 10.016251% |
| C | 6769 | 83 | 1.226178% |
| D | 6769 | 3339 | 49.327818% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7750 | 6771 | 1 | 1 | 0.01% | 0.01% |  |
| B | 7750 | 6771 | 381 | 381 | 4.92% | 5.63% |  |
| C | 7750 | 6771 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7750 | 6771 | 2991 | 2991 | 38.59% | 44.17% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 239 | 147929 | 825.66 | 869 | 851 | 178.1 |
| A | 1 | 162 | 85263 | 473.87 | 869 | 851 | 178.1 |
| A | 0 | 23 | 45312 | 249.59 | 869 | 851 | 178.1 |
| B | 4 | 239 | 979955 | 6204.01 | 820 | 798 | 157.8 |
| B | 3 | 64 | 558241 | 3532.0 | 820 | 798 | 157.8 |
| B | 12 | 111 | 17829 | 107.91 | 820 | 798 | 157.8 |
| C | 13 | 61 | 6162 | 27.08 | 845 | 852 | 196.0 |
| C | 4 | 112 | 5201 | 22.18 | 845 | 852 | 196.0 |
| C | 5 | 252 | 4316 | 17.67 | 845 | 852 | 196.0 |
| D | 12 | 110 | 6680590 | 43112.87 | 643 | 627 | 154.9 |
| D | 10 | 157 | 1696978 | 10948.35 | 643 | 627 | 154.9 |
| D | 13 | 104 | 219800 | 1414.56 | 643 | 627 | 154.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
