| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A04_112T01_9000001908_12966cztM0_level2.evt | modeM0/AS1A04_112T01_9000001908_12966cztM0_level2_quad_clean.evt |
| Size (bytes) | 203,708,160 | 38,427,840 |
| Size | 194.3 MB | 36.6 MB |
| Events in quadrant A | 1,274,635 | 260,166 |
| Events in quadrant B | 1,985,581 | 230,718 |
| Events in quadrant C | 1,143,127 | 263,221 |
| Events in quadrant D | 1,607,107 | 242,534 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 48 | 0 |
| B | 0 | 48 | 0 |
| C | 0 | 48 | 0 |
| D | 0 | 48 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 5190 | 2 |
| B | 0 | 7360 | 1 |
| C | 0 | 4886 | 1 |
| D | 0 | 6232 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 2307 | 27 | 1.170351% |
| B | 2307 | 399 | 17.295189% |
| C | 2307 | 20 | 0.866927% |
| D | 2307 | 121 | 5.244907% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 3488 | 2310 | 1 | 1 | 0.03% | 0.04% |  |
| B | 3488 | 2310 | 230 | 230 | 6.59% | 9.96% |  |
| C | 3488 | 2310 | 0 | 0 | 0.00% | 0.00% |  |
| D | 3488 | 2310 | 94 | 94 | 2.69% | 4.07% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 189 | 47286 | 769.16 | 297 | 291 | 61.1 |
| A | 1 | 162 | 27451 | 444.53 | 297 | 291 | 61.1 |
| A | 15 | 174 | 11576 | 184.7 | 297 | 291 | 61.1 |
| B | 4 | 239 | 763191 | 14416.98 | 273 | 267 | 52.9 |
| B | 0 | 219 | 115364 | 2174.99 | 273 | 267 | 52.9 |
| B | 3 | 64 | 34652 | 649.77 | 273 | 267 | 52.9 |
| C | 13 | 61 | 2169 | 27.39 | 292 | 294 | 68.4 |
| C | 0 | 207 | 1148 | 12.48 | 292 | 294 | 68.4 |
| C | 3 | 202 | 767 | 6.91 | 292 | 294 | 68.4 |
| D | 1 | 52 | 434450 | 6323.94 | 282 | 273 | 68.7 |
| D | 13 | 104 | 49664 | 719.4 | 282 | 273 | 68.7 |
| D | 8 | 195 | 18632 | 267.41 | 282 | 273 | 68.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
