| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G08_068T01_9000001922_13069cztM0_level2.evt | modeM0/AS1G08_068T01_9000001922_13069cztM0_level2_quad_clean.evt |
| Size (bytes) | 489,775,680 | 62,798,400 |
| Size | 467.1 MB | 59.9 MB |
| Events in quadrant A | 2,318,632 | 445,985 |
| Events in quadrant B | 5,077,239 | 367,457 |
| Events in quadrant C | 2,178,863 | 453,761 |
| Events in quadrant D | 4,949,280 | 313,710 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 9981 | 297 |
| B | 0 | 18571 | 425 |
| C | 0 | 9610 | 302 |
| D | 0 | 17959 | 328 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 98 | 2 |
| B | 0 | 98 | 4 |
| C | 0 | 98 | 2 |
| D | 0 | 98 | 4 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 4542 | 33 | 0.726552% |
| B | 4539 | 1289 | 28.398326% |
| C | 4537 | 13 | 0.286533% |
| D | 4534 | 1106 | 24.393472% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 5985 | 4597 | 3 | 3 | 0.05% | 0.07% |  |
| B | 5985 | 4586 | 929 | 929 | 15.52% | 20.26% |  |
| C | 5985 | 4582 | 1 | 1 | 0.02% | 0.02% |  |
| D | 5985 | 4589 | 1048 | 1048 | 17.51% | 22.84% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 189 | 90535 | 790.14 | 560 | 547 | 113.9 |
| A | 1 | 162 | 23802 | 204.19 | 560 | 547 | 113.9 |
| A | 15 | 223 | 11553 | 96.64 | 560 | 547 | 113.9 |
| B | 4 | 239 | 1775326 | 20002.69 | 470 | 458 | 88.7 |
| B | 0 | 85 | 1379539 | 15542.18 | 470 | 458 | 88.7 |
| B | 3 | 209 | 27373 | 303.33 | 470 | 458 | 88.7 |
| C | 8 | 128 | 8527 | 61.98 | 553 | 558 | 128.6 |
| C | 8 | 112 | 4536 | 30.94 | 553 | 558 | 128.6 |
| C | 13 | 61 | 4011 | 26.85 | 553 | 558 | 128.6 |
| D | 1 | 52 | 3101868 | 27883.16 | 463 | 450 | 111.2 |
| D | 14 | 34 | 64519 | 576.01 | 463 | 450 | 111.2 |
| D | 2 | 234 | 14856 | 129.52 | 463 | 450 | 111.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
