| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T02_011T01_9000001940_13138cztM0_level2.evt | modeM0/AS1T02_011T01_9000001940_13138cztM0_level2_quad_clean.evt |
| Size (bytes) | 302,497,920 | 57,398,400 |
| Size | 288.5 MB | 54.7 MB |
| Events in quadrant A | 1,903,407 | 374,485 |
| Events in quadrant B | 2,614,245 | 371,899 |
| Events in quadrant C | 1,800,766 | 374,308 |
| Events in quadrant D | 2,583,747 | 349,212 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 11 | 0 |
| D | 0 | 11 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 8121 | 2 |
| B | 0 | 10350 | 1 |
| C | 0 | 7808 | 1 |
| D | 0 | 10225 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 76 | 0 |
| B | 0 | 76 | 0 |
| C | 0 | 76 | 0 |
| D | 0 | 76 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 3799 | 50 | 1.316136% |
| B | 3799 | 335 | 8.818110% |
| C | 3799 | 30 | 0.789681% |
| D | 3799 | 180 | 4.738089% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 4880 | 3801 | 1 | 1 | 0.02% | 0.03% |  |
| B | 4880 | 3801 | 136 | 136 | 2.79% | 3.58% |  |
| C | 4880 | 3801 | 0 | 0 | 0.00% | 0.00% |  |
| D | 4880 | 3801 | 126 | 126 | 2.58% | 3.31% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 189 | 34794 | 352.62 | 470 | 461 | 97.4 |
| A | 1 | 162 | 18468 | 184.94 | 470 | 461 | 97.4 |
| A | 0 | 23 | 10836 | 106.56 | 470 | 461 | 97.4 |
| B | 4 | 239 | 422076 | 4852.73 | 456 | 445 | 86.9 |
| B | 15 | 32 | 211570 | 2429.93 | 456 | 445 | 86.9 |
| B | 0 | 85 | 101240 | 1160.09 | 456 | 445 | 86.9 |
| C | 0 | 207 | 4251 | 35.2 | 460 | 462 | 107.6 |
| C | 13 | 61 | 3356 | 26.88 | 460 | 462 | 107.6 |
| C | 14 | 234 | 1449 | 9.17 | 460 | 462 | 107.6 |
| D | 1 | 52 | 860591 | 8001.32 | 448 | 435 | 107.5 |
| D | 2 | 234 | 15623 | 141.28 | 448 | 435 | 107.5 |
| D | 1 | 7 | 6508 | 56.49 | 448 | 435 | 107.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
