| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T02_011T01_9000001940_13141cztM0_level2.evt | modeM0/AS1T02_011T01_9000001940_13141cztM0_level2_quad_clean.evt |
| Size (bytes) | 497,557,440 | 109,748,160 |
| Size | 474.5 MB | 104.7 MB |
| Events in quadrant A | 3,323,029 | 734,103 |
| Events in quadrant B | 4,732,438 | 716,964 |
| Events in quadrant C | 3,039,085 | 741,719 |
| Events in quadrant D | 3,547,190 | 692,112 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 21 | 0 |
| B | 0 | 21 | 0 |
| C | 0 | 21 | 0 |
| D | 0 | 22 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13805 | 3 |
| B | 0 | 18245 | 2 |
| C | 0 | 13024 | 2 |
| D | 0 | 14728 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 126 | 0 |
| B | 0 | 126 | 0 |
| C | 0 | 126 | 0 |
| D | 0 | 126 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6296 | 66 | 1.048285% |
| B | 6296 | 642 | 10.196950% |
| C | 6296 | 31 | 0.492376% |
| D | 6296 | 81 | 1.286531% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7557 | 6298 | 8 | 8 | 0.11% | 0.13% |  |
| B | 7557 | 6298 | 322 | 322 | 4.26% | 5.11% |  |
| C | 7557 | 6298 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7557 | 6298 | 40 | 40 | 0.53% | 0.64% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 189 | 88621 | 551.78 | 790 | 772 | 159.2 |
| A | 0 | 23 | 67307 | 417.91 | 790 | 772 | 159.2 |
| A | 4 | 2 | 57755 | 357.91 | 790 | 772 | 159.2 |
| B | 4 | 239 | 1363108 | 9708.79 | 753 | 736 | 140.3 |
| B | 0 | 85 | 251518 | 1787.17 | 753 | 736 | 140.3 |
| B | 15 | 32 | 33935 | 236.59 | 753 | 736 | 140.3 |
| C | 13 | 61 | 5641 | 27.1 | 779 | 786 | 179.1 |
| C | 3 | 202 | 1903 | 6.24 | 779 | 786 | 179.1 |
| C | 0 | 207 | 1789 | 5.6 | 779 | 786 | 179.1 |
| D | 1 | 52 | 500311 | 2723.13 | 763 | 742 | 183.5 |
| D | 8 | 195 | 85999 | 464.73 | 763 | 742 | 183.5 |
| D | 5 | 222 | 36149 | 193.0 | 763 | 742 | 183.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
