| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T02_012T07_9000001958_13187cztM0_level2.evt | modeM0/AS1T02_012T07_9000001958_13187cztM0_level2_quad_clean.evt |
| Size (bytes) | 559,333,440 | 63,452,160 |
| Size | 533.4 MB | 60.5 MB |
| Events in quadrant A | 3,313,132 | 388,564 |
| Events in quadrant B | 4,632,488 | 352,822 |
| Events in quadrant C | 2,989,817 | 387,104 |
| Events in quadrant D | 5,576,201 | 351,841 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13820 | 3 |
| B | 0 | 17694 | 2 |
| C | 0 | 13002 | 2 |
| D | 0 | 20766 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18 | 0 |
| B | 0 | 18 | 0 |
| C | 0 | 18 | 0 |
| D | 0 | 19 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 128 | 0 |
| B | 0 | 128 | 0 |
| C | 0 | 128 | 0 |
| D | 0 | 128 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6311 | 56 | 0.887340% |
| B | 6311 | 624 | 9.887498% |
| C | 6311 | 7 | 0.110917% |
| D | 6311 | 711 | 11.266043% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7607 | 6313 | 14 | 14 | 0.18% | 0.22% |  |
| B | 7607 | 6313 | 390 | 390 | 5.13% | 6.18% |  |
| C | 7607 | 6313 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7607 | 6313 | 526 | 526 | 6.91% | 8.33% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 192 | 138695 | 883.72 | 782 | 768 | 156.1 |
| A | 12 | 189 | 106629 | 678.27 | 782 | 768 | 156.1 |
| A | 8 | 15 | 23951 | 148.54 | 782 | 768 | 156.1 |
| B | 4 | 239 | 1513654 | 10741.7 | 752 | 733 | 140.8 |
| B | 3 | 64 | 52954 | 370.77 | 752 | 733 | 140.8 |
| B | 0 | 219 | 35508 | 246.9 | 752 | 733 | 140.8 |
| C | 13 | 61 | 5655 | 27.83 | 764 | 771 | 175.5 |
| C | 0 | 207 | 4464 | 21.04 | 764 | 771 | 175.5 |
| C | 15 | 208 | 4381 | 20.57 | 764 | 771 | 175.5 |
| D | 13 | 122 | 2340047 | 13633.69 | 721 | 703 | 171.6 |
| D | 1 | 52 | 306936 | 1784.73 | 721 | 703 | 171.6 |
| D | 10 | 157 | 130669 | 757.44 | 721 | 703 | 171.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
