| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G08_077T01_9000001970_13244cztM0_level2.evt | modeM0/AS1G08_077T01_9000001970_13244cztM0_level2_quad_clean.evt |
| Size (bytes) | 569,675,520 | 101,914,560 |
| Size | 543.3 MB | 97.2 MB |
| Events in quadrant A | 3,309,073 | 666,252 |
| Events in quadrant B | 7,197,591 | 607,418 |
| Events in quadrant C | 3,148,923 | 704,001 |
| Events in quadrant D | 3,158,676 | 657,707 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 27 | 0 |
| B | 0 | 27 | 0 |
| C | 0 | 27 | 0 |
| D | 0 | 27 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 134 | 0 |
| B | 0 | 134 | 0 |
| C | 0 | 134 | 0 |
| D | 0 | 134 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14225 | 3 |
| B | 0 | 25818 | 2 |
| C | 0 | 13613 | 2 |
| D | 0 | 13864 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6458 | 61 | 0.944565% |
| B | 6458 | 1663 | 25.751007% |
| C | 6458 | 58 | 0.898111% |
| D | 6458 | 50 | 0.774234% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 9169 | 6461 | 2 | 2 | 0.02% | 0.03% |  |
| B | 9168 | 6460 | 1153 | 1153 | 12.58% | 17.85% |  |
| C | 9169 | 6461 | 0 | 0 | 0.00% | 0.00% |  |
| D | 9169 | 6461 | 7 | 7 | 0.08% | 0.11% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 189 | 144458 | 897.18 | 797 | 782 | 160.1 |
| A | 15 | 239 | 63646 | 392.55 | 797 | 782 | 160.1 |
| A | 1 | 162 | 19916 | 119.48 | 797 | 782 | 160.1 |
| B | 4 | 239 | 4285927 | 32729.18 | 714 | 696 | 130.9 |
| B | 3 | 64 | 37843 | 283.72 | 714 | 696 | 130.9 |
| B | 0 | 230 | 24345 | 180.62 | 714 | 696 | 130.9 |
| C | 15 | 208 | 14439 | 74.76 | 803 | 809 | 182.3 |
| C | 13 | 61 | 5834 | 27.56 | 803 | 809 | 182.3 |
| C | 8 | 222 | 2834 | 11.11 | 803 | 809 | 182.3 |
| D | 1 | 52 | 148382 | 796.51 | 786 | 767 | 185.3 |
| D | 2 | 234 | 23612 | 123.27 | 786 | 767 | 185.3 |
| D | 14 | 34 | 11472 | 57.76 | 786 | 767 | 185.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
