| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A04_167T02_9000001974_13274cztM0_level2.evt | modeM0/AS1A04_167T02_9000001974_13274cztM0_level2_quad_clean.evt |
| Size (bytes) | 552,049,920 | 96,609,600 |
| Size | 526.5 MB | 92.1 MB |
| Events in quadrant A | 4,064,174 | 619,574 |
| Events in quadrant B | 4,202,957 | 622,849 |
| Events in quadrant C | 3,041,146 | 651,483 |
| Events in quadrant D | 4,987,473 | 595,967 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 124 | 0 |
| B | 0 | 124 | 0 |
| C | 0 | 124 | 0 |
| D | 0 | 124 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16301 | 3 |
| B | 0 | 16459 | 2 |
| C | 0 | 13107 | 2 |
| D | 0 | 19268 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16 | 0 |
| B | 0 | 16 | 0 |
| C | 0 | 16 | 0 |
| D | 0 | 17 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6253 | 176 | 2.814649% |
| B | 6253 | 598 | 9.563410% |
| C | 6253 | 37 | 0.591716% |
| D | 6253 | 397 | 6.348953% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7474 | 6255 | 101 | 101 | 1.35% | 1.61% |  |
| B | 7474 | 6254 | 318 | 318 | 4.25% | 5.08% |  |
| C | 7474 | 6255 | 1 | 1 | 0.01% | 0.02% |  |
| D | 7474 | 6255 | 274 | 274 | 3.67% | 4.38% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 239 | 814667 | 5212.04 | 772 | 758 | 156.2 |
| A | 8 | 15 | 226400 | 1444.95 | 772 | 758 | 156.2 |
| A | 4 | 2 | 41007 | 257.74 | 772 | 758 | 156.2 |
| B | 4 | 239 | 1161140 | 8499.0 | 728 | 712 | 136.5 |
| B | 0 | 244 | 95211 | 692.11 | 728 | 712 | 136.5 |
| B | 4 | 173 | 43108 | 310.51 | 728 | 712 | 136.5 |
| C | 6 | 96 | 23341 | 127.59 | 771 | 778 | 176.8 |
| C | 15 | 208 | 7585 | 38.49 | 771 | 778 | 176.8 |
| C | 13 | 61 | 5542 | 26.94 | 771 | 778 | 176.8 |
| D | 1 | 52 | 2007674 | 11256.63 | 740 | 718 | 178.3 |
| D | 5 | 222 | 127290 | 709.92 | 740 | 718 | 178.3 |
| D | 8 | 195 | 31652 | 173.5 | 740 | 718 | 178.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
