| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A04_103T01_9000001988_13386cztM0_level2.evt | modeM0/AS1A04_103T01_9000001988_13386cztM0_level2_quad_clean.evt |
| Size (bytes) | 519,488,640 | 66,643,200 |
| Size | 495.4 MB | 63.6 MB |
| Events in quadrant A | 3,422,005 | 391,495 |
| Events in quadrant B | 3,805,146 | 395,966 |
| Events in quadrant C | 3,602,232 | 390,035 |
| Events in quadrant D | 4,441,485 | 365,609 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14616 | 3 |
| B | 0 | 15712 | 2 |
| C | 0 | 15014 | 2 |
| D | 0 | 17679 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 140 | 0 |
| B | 0 | 140 | 0 |
| C | 0 | 140 | 0 |
| D | 0 | 140 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 13 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6802 | 93 | 1.367245% |
| B | 6802 | 137 | 2.014113% |
| C | 6802 | 75 | 1.102617% |
| D | 6802 | 220 | 3.234343% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7948 | 6804 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7948 | 6804 | 16 | 16 | 0.20% | 0.24% |  |
| C | 7948 | 6804 | 3 | 3 | 0.04% | 0.04% |  |
| D | 7948 | 6804 | 156 | 156 | 1.96% | 2.29% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 69 | 24478 | 135.32 | 877 | 859 | 174.5 |
| A | 1 | 162 | 12803 | 68.43 | 877 | 859 | 174.5 |
| A | 0 | 226 | 7988 | 40.84 | 877 | 859 | 174.5 |
| B | 0 | 85 | 166548 | 1014.08 | 873 | 851 | 163.4 |
| B | 11 | 51 | 63092 | 380.92 | 873 | 851 | 163.4 |
| B | 0 | 197 | 36112 | 215.8 | 873 | 851 | 163.4 |
| C | 3 | 233 | 195324 | 1000.24 | 847 | 853 | 194.4 |
| C | 14 | 220 | 102471 | 522.66 | 847 | 853 | 194.4 |
| C | 13 | 61 | 5898 | 25.95 | 847 | 853 | 194.4 |
| D | 1 | 52 | 1159616 | 5852.27 | 838 | 814 | 198.0 |
| D | 13 | 249 | 32613 | 160.59 | 838 | 814 | 198.0 |
| D | 5 | 222 | 22880 | 111.44 | 838 | 814 | 198.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
