| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A04_103T01_9000001988_13445cztM0_level2.evt | modeM0/AS1A04_103T01_9000001988_13445cztM0_level2_quad_clean.evt |
| Size (bytes) | 479,053,440 | 66,087,360 |
| Size | 456.9 MB | 63.0 MB |
| Events in quadrant A | 3,424,113 | 388,061 |
| Events in quadrant B | 3,519,225 | 393,213 |
| Events in quadrant C | 3,406,120 | 387,201 |
| Events in quadrant D | 3,706,808 | 368,348 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14438 | 3 |
| B | 0 | 14719 | 2 |
| C | 0 | 14382 | 2 |
| D | 0 | 15481 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 134 | 0 |
| B | 0 | 134 | 0 |
| C | 0 | 134 | 0 |
| D | 0 | 134 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18 | 0 |
| B | 0 | 18 | 0 |
| C | 0 | 18 | 0 |
| D | 0 | 19 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6661 | 80 | 1.201021% |
| B | 6661 | 90 | 1.351148% |
| C | 6661 | 64 | 0.960817% |
| D | 6661 | 90 | 1.351148% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7912 | 6662 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7912 | 6662 | 3 | 3 | 0.04% | 0.05% |  |
| C | 7912 | 6662 | 2 | 2 | 0.03% | 0.03% |  |
| D | 7912 | 6662 | 25 | 25 | 0.32% | 0.38% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 1 | 162 | 13084 | 69.9 | 884 | 867 | 174.8 |
| A | 0 | 226 | 8011 | 40.87 | 884 | 867 | 174.8 |
| A | 12 | 194 | 6653 | 33.1 | 884 | 867 | 174.8 |
| B | 3 | 209 | 23493 | 139.34 | 880 | 861 | 162.4 |
| B | 0 | 214 | 20325 | 119.84 | 880 | 861 | 162.4 |
| B | 12 | 111 | 18704 | 109.86 | 880 | 861 | 162.4 |
| C | 3 | 233 | 53028 | 268.14 | 853 | 858 | 194.6 |
| C | 14 | 220 | 27528 | 137.08 | 853 | 858 | 194.6 |
| C | 13 | 61 | 6154 | 27.22 | 853 | 858 | 194.6 |
| D | 13 | 249 | 362278 | 1786.8 | 848 | 824 | 202.3 |
| D | 8 | 195 | 115777 | 568.25 | 848 | 824 | 202.3 |
| D | 2 | 136 | 28354 | 136.09 | 848 | 824 | 202.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
