| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T02_020T01_9000001990_13518cztM0_level2.evt | modeM0/AS1T02_020T01_9000001990_13518cztM0_level2_quad_clean.evt |
| Size (bytes) | 492,641,280 | 91,013,760 |
| Size | 469.8 MB | 86.8 MB |
| Events in quadrant A | 3,327,968 | 589,408 |
| Events in quadrant B | 4,282,321 | 625,422 |
| Events in quadrant C | 3,517,881 | 568,611 |
| Events in quadrant D | 3,370,535 | 539,835 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13681 | 3 |
| B | 0 | 16630 | 2 |
| C | 0 | 14212 | 2 |
| D | 0 | 13902 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 13 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 126 | 0 |
| B | 0 | 126 | 0 |
| C | 0 | 126 | 0 |
| D | 0 | 126 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6202 | 140 | 2.257336% |
| B | 6202 | 455 | 7.336343% |
| C | 6202 | 117 | 1.886488% |
| D | 6202 | 137 | 2.208965% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7433 | 6203 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7433 | 6203 | 276 | 276 | 3.71% | 4.45% |  |
| C | 7433 | 6203 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7433 | 6203 | 9 | 9 | 0.12% | 0.15% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 1 | 162 | 20324 | 112.91 | 855 | 840 | 172.6 |
| A | 0 | 226 | 7721 | 39.88 | 855 | 840 | 172.6 |
| A | 12 | 194 | 6497 | 32.78 | 855 | 840 | 172.6 |
| B | 3 | 64 | 939392 | 6031.58 | 832 | 814 | 155.6 |
| B | 4 | 142 | 23848 | 148.02 | 832 | 814 | 155.6 |
| B | 3 | 209 | 22261 | 137.82 | 832 | 814 | 155.6 |
| C | 3 | 233 | 324143 | 1726.59 | 818 | 824 | 187.3 |
| C | 13 | 61 | 5926 | 27.24 | 818 | 824 | 187.3 |
| C | 0 | 207 | 4966 | 22.12 | 818 | 824 | 187.3 |
| D | 13 | 104 | 108383 | 561.19 | 820 | 800 | 191.7 |
| D | 8 | 195 | 89336 | 461.83 | 820 | 800 | 191.7 |
| D | 2 | 234 | 25294 | 127.77 | 820 | 800 | 191.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
