| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A04_180T01_9000002000_13567cztM0_level2.evt | modeM0/AS1A04_180T01_9000002000_13567cztM0_level2_quad_clean.evt |
| Size (bytes) | 395,156,160 | 67,233,600 |
| Size | 376.9 MB | 64.1 MB |
| Events in quadrant A | 2,562,630 | 425,704 |
| Events in quadrant B | 2,753,069 | 422,272 |
| Events in quadrant C | 2,721,853 | 422,744 |
| Events in quadrant D | 3,574,154 | 398,757 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 106 | 0 |
| B | 0 | 106 | 0 |
| C | 0 | 106 | 0 |
| D | 0 | 106 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 3 | 0 |
| B | 0 | 3 | 0 |
| C | 0 | 3 | 0 |
| D | 0 | 3 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11012 | 1 |
| B | 0 | 11569 | 1 |
| C | 0 | 11405 | 1 |
| D | 0 | 14206 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5230 | 102 | 1.950287% |
| B | 5230 | 171 | 3.269598% |
| C | 5230 | 123 | 2.351816% |
| D | 5230 | 283 | 5.411090% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 5526 | 5231 | 0 | 0 | 0.00% | 0.00% |  |
| B | 5526 | 5231 | 41 | 41 | 0.74% | 0.78% |  |
| C | 5526 | 5231 | 4 | 4 | 0.07% | 0.08% |  |
| D | 5526 | 5231 | 143 | 143 | 2.59% | 2.73% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 1 | 162 | 34095 | 247.51 | 645 | 630 | 135.2 |
| A | 1 | 178 | 12255 | 85.98 | 645 | 630 | 135.2 |
| A | 1 | 161 | 10755 | 74.89 | 645 | 630 | 135.2 |
| B | 3 | 64 | 110919 | 879.35 | 639 | 623 | 125.4 |
| B | 0 | 190 | 73028 | 577.26 | 639 | 623 | 125.4 |
| B | 0 | 182 | 29751 | 232.23 | 639 | 623 | 125.4 |
| C | 3 | 233 | 251975 | 1696.5 | 625 | 628 | 148.2 |
| C | 14 | 234 | 15052 | 97.36 | 625 | 628 | 148.2 |
| C | 8 | 128 | 8185 | 51.01 | 625 | 628 | 148.2 |
| D | 8 | 195 | 463512 | 3064.44 | 616 | 599 | 151.1 |
| D | 2 | 14 | 245293 | 1619.85 | 616 | 599 | 151.1 |
| D | 5 | 222 | 237191 | 1566.22 | 616 | 599 | 151.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
