| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A04_193T01_9000002004_13592cztM0_level2.evt | modeM0/AS1A04_193T01_9000002004_13592cztM0_level2_quad_clean.evt |
| Size (bytes) | 480,646,080 | 125,259,840 |
| Size | 458.4 MB | 119.5 MB |
| Events in quadrant A | 2,983,969 | 858,990 |
| Events in quadrant B | 3,557,565 | 855,972 |
| Events in quadrant C | 3,055,675 | 852,428 |
| Events in quadrant D | 4,544,073 | 799,331 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12678 | 2 |
| B | 0 | 14297 | 1 |
| C | 0 | 12846 | 1 |
| D | 0 | 17499 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 124 | 0 |
| B | 0 | 124 | 0 |
| C | 0 | 124 | 0 |
| D | 0 | 124 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6116 | 105 | 1.716808% |
| B | 6116 | 202 | 3.302812% |
| C | 6116 | 82 | 1.340746% |
| D | 6116 | 402 | 6.572923% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7317 | 6118 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7317 | 6118 | 105 | 105 | 1.44% | 1.72% |  |
| C | 7317 | 6118 | 3 | 3 | 0.04% | 0.05% |  |
| D | 7317 | 6118 | 302 | 302 | 4.13% | 4.94% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 1 | 162 | 18455 | 116.77 | 765 | 750 | 151.6 |
| A | 15 | 69 | 8116 | 48.58 | 765 | 750 | 151.6 |
| A | 0 | 226 | 7181 | 42.42 | 765 | 750 | 151.6 |
| B | 0 | 182 | 353013 | 2545.56 | 749 | 732 | 138.4 |
| B | 0 | 85 | 97394 | 698.47 | 749 | 732 | 138.4 |
| B | 0 | 189 | 72116 | 515.82 | 749 | 732 | 138.4 |
| C | 3 | 233 | 153438 | 910.87 | 736 | 740 | 167.6 |
| C | 0 | 207 | 18877 | 108.19 | 736 | 740 | 167.6 |
| C | 14 | 234 | 11389 | 63.52 | 736 | 740 | 167.6 |
| D | 13 | 249 | 808223 | 4583.79 | 733 | 710 | 176.2 |
| D | 5 | 222 | 387666 | 2196.53 | 733 | 710 | 176.2 |
| D | 13 | 122 | 313875 | 1777.66 | 733 | 710 | 176.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
