| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C03_015T02_9000002008_13604cztM0_level2.evt | modeM0/AS1C03_015T02_9000002008_13604cztM0_level2_quad_clean.evt |
| Size (bytes) | 441,005,760 | 120,654,720 |
| Size | 420.6 MB | 115.1 MB |
| Events in quadrant A | 2,809,968 | 822,053 |
| Events in quadrant B | 3,198,572 | 835,551 |
| Events in quadrant C | 2,809,256 | 816,189 |
| Events in quadrant D | 4,136,891 | 767,944 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 120 | 0 |
| B | 0 | 120 | 0 |
| C | 0 | 120 | 0 |
| D | 0 | 120 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12149 | 2 |
| B | 0 | 13309 | 1 |
| C | 0 | 12172 | 1 |
| D | 0 | 16437 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5898 | 47 | 0.796880% |
| B | 5898 | 84 | 1.424212% |
| C | 5898 | 35 | 0.593421% |
| D | 5898 | 244 | 4.136996% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7149 | 5900 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7149 | 5900 | 8 | 8 | 0.11% | 0.14% |  |
| C | 7149 | 5900 | 1 | 1 | 0.01% | 0.02% |  |
| D | 7149 | 5900 | 196 | 196 | 2.74% | 3.32% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 1 | 162 | 21016 | 139.45 | 722 | 707 | 145.6 |
| A | 1 | 178 | 6649 | 40.8 | 722 | 707 | 145.6 |
| A | 0 | 226 | 6523 | 39.93 | 722 | 707 | 145.6 |
| B | 0 | 219 | 227744 | 1699.14 | 720 | 702 | 133.6 |
| B | 0 | 85 | 48963 | 361.18 | 720 | 702 | 133.6 |
| B | 4 | 173 | 38723 | 284.54 | 720 | 702 | 133.6 |
| C | 3 | 233 | 78577 | 495.22 | 690 | 694 | 157.3 |
| C | 0 | 207 | 23531 | 145.21 | 690 | 694 | 157.3 |
| C | 14 | 234 | 7402 | 42.65 | 690 | 694 | 157.3 |
| D | 13 | 122 | 1055221 | 6567.93 | 682 | 663 | 160.6 |
| D | 8 | 195 | 197138 | 1223.67 | 682 | 663 | 160.6 |
| D | 13 | 249 | 115661 | 716.22 | 682 | 663 | 160.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
