| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G08_038T01_9000002018_13630cztM0_level2.evt | modeM0/AS1G08_038T01_9000002018_13630cztM0_level2_quad_clean.evt |
| Size (bytes) | 523,474,560 | 100,293,120 |
| Size | 499.2 MB | 95.6 MB |
| Events in quadrant A | 3,278,572 | 599,429 |
| Events in quadrant B | 3,772,620 | 627,367 |
| Events in quadrant C | 3,553,493 | 682,153 |
| Events in quadrant D | 4,768,167 | 634,908 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14629 | 3 |
| B | 0 | 15860 | 2 |
| C | 0 | 14921 | 2 |
| D | 0 | 18936 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 146 | 0 |
| B | 0 | 146 | 0 |
| C | 0 | 146 | 0 |
| D | 0 | 146 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 20 | 0 |
| B | 0 | 20 | 0 |
| C | 0 | 20 | 0 |
| D | 0 | 20 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7086 | 42 | 0.592718% |
| B | 7086 | 95 | 1.340672% |
| C | 7086 | 35 | 0.493932% |
| D | 7086 | 96 | 1.354784% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 9097 | 7089 | 7 | 7 | 0.08% | 0.10% |  |
| B | 9097 | 7089 | 12 | 12 | 0.13% | 0.17% |  |
| C | 9097 | 7089 | 4 | 4 | 0.04% | 0.06% |  |
| D | 9097 | 7089 | 19 | 19 | 0.21% | 0.27% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 69 | 14975 | 82.63 | 840 | 820 | 171.3 |
| A | 3 | 0 | 12729 | 69.52 | 840 | 820 | 171.3 |
| A | 1 | 162 | 12648 | 69.04 | 840 | 820 | 171.3 |
| B | 0 | 219 | 320024 | 1961.78 | 848 | 824 | 162.7 |
| B | 0 | 214 | 38344 | 230.59 | 848 | 824 | 162.7 |
| B | 3 | 64 | 28017 | 167.13 | 848 | 824 | 162.7 |
| C | 3 | 233 | 239619 | 1228.86 | 845 | 856 | 194.3 |
| C | 14 | 234 | 15460 | 75.16 | 845 | 856 | 194.3 |
| C | 13 | 61 | 5978 | 26.36 | 845 | 856 | 194.3 |
| D | 13 | 122 | 1291350 | 6479.53 | 829 | 807 | 199.2 |
| D | 8 | 195 | 153220 | 765.23 | 829 | 807 | 199.2 |
| D | 5 | 222 | 118961 | 593.23 | 829 | 807 | 199.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
