| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G08_083T03_9000002022_13649cztM0_level2.evt | modeM0/AS1G08_083T03_9000002022_13649cztM0_level2_quad_clean.evt |
| Size (bytes) | 458,562,240 | 65,954,880 |
| Size | 437.3 MB | 62.9 MB |
| Events in quadrant A | 3,251,848 | 392,957 |
| Events in quadrant B | 3,373,588 | 401,766 |
| Events in quadrant C | 3,389,495 | 396,291 |
| Events in quadrant D | 3,456,528 | 377,973 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13148 | 3 |
| B | 0 | 13607 | 2 |
| C | 0 | 13710 | 2 |
| D | 0 | 13780 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 20 | 0 |
| B | 0 | 20 | 0 |
| C | 0 | 20 | 0 |
| D | 0 | 21 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 126 | 0 |
| B | 0 | 126 | 0 |
| C | 0 | 126 | 0 |
| D | 0 | 126 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6126 | 56 | 0.914136% |
| B | 6126 | 73 | 1.191642% |
| C | 6126 | 48 | 0.783546% |
| D | 6126 | 54 | 0.881489% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7487 | 6128 | 10 | 10 | 0.13% | 0.16% |  |
| B | 7487 | 6128 | 0 | 0 | 0.00% | 0.00% |  |
| C | 7487 | 6128 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7487 | 6127 | 13 | 13 | 0.17% | 0.21% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 96 | 44827 | 263.17 | 833 | 818 | 167.2 |
| A | 0 | 226 | 7347 | 39.04 | 833 | 818 | 167.2 |
| A | 12 | 194 | 6329 | 32.96 | 833 | 818 | 167.2 |
| B | 0 | 219 | 71708 | 452.69 | 839 | 821 | 156.6 |
| B | 12 | 111 | 17409 | 105.93 | 839 | 821 | 156.6 |
| B | 11 | 111 | 14591 | 87.94 | 839 | 821 | 156.6 |
| C | 3 | 233 | 175327 | 937.16 | 823 | 831 | 186.2 |
| C | 13 | 61 | 5979 | 27.65 | 823 | 831 | 186.2 |
| C | 14 | 234 | 4165 | 17.91 | 823 | 831 | 186.2 |
| D | 8 | 195 | 240942 | 1264.88 | 809 | 788 | 189.9 |
| D | 13 | 249 | 57688 | 299.69 | 809 | 788 | 189.9 |
| D | 2 | 136 | 57459 | 298.48 | 809 | 788 | 189.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
