| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G08_070T01_9000002028_13683cztM0_level2.evt | modeM0/AS1G08_070T01_9000002028_13683cztM0_level2_quad_clean.evt |
| Size (bytes) | 729,325,440 | 92,234,880 |
| Size | 695.5 MB | 88.0 MB |
| Events in quadrant A | 4,163,379 | 571,302 |
| Events in quadrant B | 4,599,832 | 607,131 |
| Events in quadrant C | 4,238,600 | 552,705 |
| Events in quadrant D | 8,535,886 | 496,430 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 166 | 0 |
| B | 0 | 166 | 0 |
| C | 0 | 166 | 0 |
| D | 0 | 166 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 1 | 0 |
| B | 0 | 1 | 0 |
| C | 0 | 1 | 0 |
| D | 0 | 1 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 17666 | 5 |
| B | 0 | 18713 | 4 |
| C | 0 | 17641 | 4 |
| D | 0 | 31111 | 4 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 8121 | 447 | 5.504248% |
| B | 8121 | 514 | 6.329270% |
| C | 8121 | 338 | 4.162049% |
| D | 8121 | 1184 | 14.579485% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8327 | 8126 | 5 | 5 | 0.06% | 0.06% |  |
| B | 8327 | 8126 | 20 | 20 | 0.24% | 0.25% |  |
| C | 8327 | 8126 | 1 | 1 | 0.01% | 0.01% |  |
| D | 8327 | 8126 | 721 | 721 | 8.66% | 8.87% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 69 | 52820 | 235.09 | 1064 | 1039 | 220.3 |
| A | 1 | 162 | 14189 | 59.7 | 1064 | 1039 | 220.3 |
| A | 0 | 226 | 9459 | 38.23 | 1064 | 1039 | 220.3 |
| B | 0 | 219 | 198450 | 946.56 | 1063 | 1038 | 208.6 |
| B | 8 | 250 | 119414 | 567.59 | 1063 | 1038 | 208.6 |
| B | 3 | 64 | 34731 | 161.55 | 1063 | 1038 | 208.6 |
| C | 3 | 233 | 214731 | 878.17 | 1030 | 1036 | 243.3 |
| C | 13 | 61 | 7396 | 26.14 | 1030 | 1036 | 243.3 |
| C | 14 | 234 | 5950 | 20.19 | 1030 | 1036 | 243.3 |
| D | 13 | 122 | 3507953 | 13258.59 | 979 | 956 | 264.5 |
| D | 5 | 222 | 487388 | 1839.01 | 979 | 956 | 264.5 |
| D | 8 | 195 | 306259 | 1154.23 | 979 | 956 | 264.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
