| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A04_199T01_9000002040_13803cztM0_level2.evt | modeM0/AS1A04_199T01_9000002040_13803cztM0_level2_quad_clean.evt |
| Size (bytes) | 482,621,760 | 87,252,480 |
| Size | 460.3 MB | 83.2 MB |
| Events in quadrant A | 3,253,364 | 550,399 |
| Events in quadrant B | 3,297,363 | 557,578 |
| Events in quadrant C | 3,072,352 | 551,106 |
| Events in quadrant D | 4,543,964 | 521,940 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 9 | 0 |
| B | 0 | 9 | 0 |
| C | 0 | 9 | 0 |
| D | 0 | 9 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 136 | 0 |
| B | 0 | 136 | 0 |
| C | 0 | 136 | 0 |
| D | 0 | 136 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13985 | 3 |
| B | 0 | 14063 | 2 |
| C | 0 | 13480 | 2 |
| D | 0 | 17968 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6608 | 41 | 0.620460% |
| B | 6608 | 52 | 0.786925% |
| C | 6608 | 17 | 0.257264% |
| D | 6609 | 186 | 2.814344% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7564 | 6610 | 8 | 8 | 0.11% | 0.12% |  |
| B | 7564 | 6610 | 14 | 14 | 0.19% | 0.21% |  |
| C | 7564 | 6610 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7565 | 6611 | 169 | 169 | 2.23% | 2.56% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 9 | 143 | 121346 | 751.05 | 784 | 766 | 160.5 |
| A | 8 | 15 | 93879 | 579.97 | 784 | 766 | 160.5 |
| A | 1 | 162 | 15519 | 91.89 | 784 | 766 | 160.5 |
| B | 0 | 219 | 72247 | 475.79 | 785 | 765 | 150.2 |
| B | 4 | 80 | 38991 | 254.43 | 785 | 765 | 150.2 |
| B | 0 | 214 | 32912 | 213.97 | 785 | 765 | 150.2 |
| C | 3 | 233 | 74937 | 416.32 | 766 | 770 | 178.1 |
| C | 4 | 175 | 6669 | 33.11 | 766 | 770 | 178.1 |
| C | 13 | 61 | 5431 | 26.16 | 766 | 770 | 178.1 |
| D | 1 | 52 | 664700 | 3514.45 | 756 | 737 | 188.9 |
| D | 5 | 222 | 496958 | 2626.57 | 756 | 737 | 188.9 |
| D | 10 | 157 | 327755 | 1730.95 | 756 | 737 | 188.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
