| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A04_199T01_9000002040_13822cztM0_level2.evt | modeM0/AS1A04_199T01_9000002040_13822cztM0_level2_quad_clean.evt |
| Size (bytes) | 516,677,760 | 84,692,160 |
| Size | 492.7 MB | 80.8 MB |
| Events in quadrant A | 3,029,698 | 544,610 |
| Events in quadrant B | 3,303,191 | 563,955 |
| Events in quadrant C | 3,031,583 | 543,255 |
| Events in quadrant D | 5,868,191 | 485,282 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 23 | 0 |
| B | 0 | 23 | 0 |
| C | 0 | 23 | 0 |
| D | 0 | 24 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 124 | 0 |
| B | 0 | 124 | 0 |
| C | 0 | 124 | 0 |
| D | 0 | 124 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12746 | 3 |
| B | 0 | 13541 | 2 |
| C | 0 | 12737 | 2 |
| D | 0 | 21661 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6126 | 25 | 0.408097% |
| B | 6126 | 63 | 1.028404% |
| C | 6126 | 16 | 0.261182% |
| D | 6126 | 376 | 6.137773% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7437 | 6128 | 3 | 3 | 0.04% | 0.05% |  |
| B | 7437 | 6128 | 20 | 20 | 0.27% | 0.33% |  |
| C | 7437 | 6128 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7436 | 6126 | 340 | 340 | 4.57% | 5.55% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 15 | 16334 | 98.55 | 778 | 763 | 158.0 |
| A | 15 | 69 | 9976 | 58.31 | 778 | 763 | 158.0 |
| A | 1 | 162 | 8733 | 50.44 | 778 | 763 | 158.0 |
| B | 3 | 64 | 67062 | 448.19 | 786 | 769 | 147.9 |
| B | 4 | 80 | 45611 | 303.16 | 786 | 769 | 147.9 |
| B | 3 | 209 | 44131 | 293.16 | 786 | 769 | 147.9 |
| C | 3 | 233 | 60917 | 344.17 | 757 | 762 | 174.8 |
| C | 4 | 175 | 16754 | 91.5 | 757 | 762 | 174.8 |
| C | 13 | 61 | 5474 | 26.96 | 757 | 762 | 174.8 |
| D | 10 | 157 | 1205324 | 6822.89 | 729 | 709 | 176.6 |
| D | 5 | 222 | 893105 | 5054.49 | 729 | 709 | 176.6 |
| D | 13 | 122 | 780340 | 4415.8 | 729 | 709 | 176.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
