| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A04_199T01_9000002040_13837cztM0_level2.evt | modeM0/AS1A04_199T01_9000002040_13837cztM0_level2_quad_clean.evt |
| Size (bytes) | 479,476,800 | 83,194,560 |
| Size | 457.3 MB | 79.3 MB |
| Events in quadrant A | 3,053,084 | 530,405 |
| Events in quadrant B | 3,223,633 | 545,614 |
| Events in quadrant C | 3,125,151 | 527,050 |
| Events in quadrant D | 4,696,667 | 481,760 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 23 | 0 |
| B | 0 | 23 | 0 |
| C | 0 | 23 | 0 |
| D | 0 | 24 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 128 | 0 |
| B | 0 | 128 | 0 |
| C | 0 | 128 | 0 |
| D | 0 | 128 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12883 | 3 |
| B | 0 | 13334 | 2 |
| C | 0 | 12926 | 2 |
| D | 0 | 18229 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6217 | 22 | 0.353868% |
| B | 6217 | 47 | 0.755992% |
| C | 6217 | 13 | 0.209104% |
| D | 6217 | 347 | 5.581470% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7558 | 6218 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7558 | 6219 | 4 | 4 | 0.05% | 0.06% |  |
| C | 7558 | 6219 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7558 | 6219 | 259 | 259 | 3.43% | 4.16% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 1 | 162 | 8717 | 49.63 | 791 | 775 | 160.0 |
| A | 0 | 226 | 6885 | 38.18 | 791 | 775 | 160.0 |
| A | 12 | 194 | 5781 | 31.28 | 791 | 775 | 160.0 |
| B | 3 | 64 | 26478 | 171.43 | 799 | 781 | 149.9 |
| B | 0 | 219 | 22687 | 146.14 | 799 | 781 | 149.9 |
| B | 4 | 80 | 21686 | 139.47 | 799 | 781 | 149.9 |
| C | 3 | 233 | 113930 | 634.18 | 770 | 774 | 178.4 |
| C | 14 | 234 | 7473 | 37.54 | 770 | 774 | 178.4 |
| C | 13 | 61 | 5621 | 27.17 | 770 | 774 | 178.4 |
| D | 1 | 52 | 857149 | 4587.36 | 739 | 721 | 186.7 |
| D | 10 | 157 | 737099 | 3944.33 | 739 | 721 | 186.7 |
| D | 13 | 122 | 131235 | 699.08 | 739 | 721 | 186.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
