| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A04_199T01_9000002040_13854cztM0_level2.evt | modeM0/AS1A04_199T01_9000002040_13854cztM0_level2_quad_clean.evt |
| Size (bytes) | 497,424,960 | 68,382,720 |
| Size | 474.4 MB | 65.2 MB |
| Events in quadrant A | 3,361,208 | 406,371 |
| Events in quadrant B | 3,804,895 | 396,728 |
| Events in quadrant C | 3,301,964 | 400,605 |
| Events in quadrant D | 4,127,045 | 384,959 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10 | 0 |
| B | 0 | 10 | 0 |
| C | 0 | 10 | 0 |
| D | 0 | 11 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 140 | 0 |
| B | 0 | 140 | 0 |
| C | 0 | 140 | 0 |
| D | 0 | 140 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14415 | 3 |
| B | 0 | 15669 | 2 |
| C | 0 | 14236 | 2 |
| D | 0 | 16918 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6915 | 78 | 1.127983% |
| B | 6915 | 233 | 3.369487% |
| C | 6915 | 38 | 0.549530% |
| D | 6915 | 89 | 1.287057% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7841 | 6916 | 17 | 17 | 0.22% | 0.25% |  |
| B | 7841 | 6916 | 161 | 161 | 2.05% | 2.33% |  |
| C | 7841 | 6916 | 2 | 2 | 0.03% | 0.03% |  |
| D | 7841 | 6916 | 50 | 50 | 0.64% | 0.72% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 9 | 143 | 83242 | 480.38 | 843 | 824 | 171.6 |
| A | 8 | 15 | 20801 | 116.44 | 843 | 824 | 171.6 |
| A | 0 | 226 | 7577 | 39.36 | 843 | 824 | 171.6 |
| B | 3 | 64 | 444641 | 2784.58 | 832 | 811 | 159.4 |
| B | 3 | 209 | 46095 | 284.11 | 832 | 811 | 159.4 |
| B | 0 | 219 | 37796 | 232.04 | 832 | 811 | 159.4 |
| C | 3 | 233 | 95933 | 495.6 | 820 | 824 | 191.9 |
| C | 6 | 253 | 8279 | 38.85 | 820 | 824 | 191.9 |
| C | 13 | 61 | 6044 | 27.2 | 820 | 824 | 191.9 |
| D | 1 | 52 | 347349 | 1620.08 | 805 | 789 | 213.9 |
| D | 10 | 157 | 239893 | 1117.75 | 805 | 789 | 213.9 |
| D | 13 | 122 | 188393 | 877.0 | 805 | 789 | 213.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
