| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A04_010T01_9000002046_13880cztM0_level2.evt | modeM0/AS1A04_010T01_9000002046_13880cztM0_level2_quad_clean.evt |
| Size (bytes) | 521,072,640 | 93,836,160 |
| Size | 496.9 MB | 89.5 MB |
| Events in quadrant A | 4,438,321 | 594,559 |
| Events in quadrant B | 3,306,488 | 618,018 |
| Events in quadrant C | 3,204,874 | 612,171 |
| Events in quadrant D | 4,402,361 | 575,920 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16 | 0 |
| B | 0 | 16 | 0 |
| C | 0 | 16 | 0 |
| D | 0 | 17 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 128 | 0 |
| B | 0 | 128 | 0 |
| C | 0 | 128 | 0 |
| D | 0 | 128 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 17196 | 3 |
| B | 0 | 13826 | 2 |
| C | 0 | 13443 | 2 |
| D | 0 | 17312 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6319 | 752 | 11.900617% |
| B | 6319 | 70 | 1.107770% |
| C | 6319 | 40 | 0.633012% |
| D | 6319 | 212 | 3.354961% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7595 | 6320 | 475 | 475 | 6.25% | 7.52% |  |
| B | 7595 | 6320 | 1 | 1 | 0.01% | 0.02% |  |
| C | 7595 | 6320 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7595 | 6320 | 166 | 166 | 2.19% | 2.63% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 23 | 1328121 | 8443.06 | 777 | 763 | 157.2 |
| A | 0 | 226 | 95875 | 604.99 | 777 | 763 | 157.2 |
| A | 4 | 2 | 27667 | 171.13 | 777 | 763 | 157.2 |
| B | 0 | 189 | 27672 | 176.79 | 812 | 794 | 152.0 |
| B | 0 | 197 | 22527 | 142.95 | 812 | 794 | 152.0 |
| B | 3 | 209 | 21168 | 134.01 | 812 | 794 | 152.0 |
| C | 3 | 233 | 106592 | 577.35 | 795 | 800 | 183.2 |
| C | 13 | 61 | 5501 | 25.66 | 795 | 800 | 183.2 |
| C | 14 | 234 | 2000 | 6.55 | 795 | 800 | 183.2 |
| D | 13 | 122 | 921996 | 5040.5 | 774 | 757 | 182.8 |
| D | 5 | 222 | 191048 | 1041.17 | 774 | 757 | 182.8 |
| D | 1 | 52 | 100015 | 543.08 | 774 | 757 | 182.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
